Thermal Conductivity Testing Machine( Plain Board and Heat Flow Calculation)
TBTTCDR-1
The popular way that using the heat flow meter to test the thermal conductivity and resistivity, together with the computer can achieve the auto inspection and report generation. This testing method easy, quick and good repeatability, which is suitable for the heat transfering R&D of the metal materials. It can also used for the test of plastic, rubber, ceramic, glass, graphite and other heat insulating material.
1,The area of heat conductivity: sheet sample 0.015-5W/mk, accuracy less than 5%.
2,Round column sample 3-400W/mk, accuracy less than 5%.
3,Heat surface temp.: room temp.- 99.99℃, use high temp. digital displayer to detect the temperature, 0.2 level accuracy. DPI 0.01 ℃.
4,Cold surface: room temp. use high temp. digital displayer to detect the temperature, 0.2 level accuracy. DPI 0.01 ℃.
5,Heat surface temp. control: room temp.- 99.99℃, use high temp. digital displayer to detect the temperature, 0.2 level accuracy. DPI 0.01 ℃. The flat type heater, two-way controllable Si.
6,Cold surface use air blast cooling.
7,Use computer to test automatically.
8,Use WPY heat flow meter, heat flow feature 23.26w/m2*mV.
9,Use plexiglass wind cover, so that the whole test course can be observed directly.
10,Cold and hot plate heat transferring area: 150×150(mm)
11,Cold and hot plate adjustable gap distance: 0-160(mm)
Package
---Carton box, wooden case or specified package
1) Inner package: dust-proof plastic bag
2) Outer package: standard export wooden case with pallet
3) Suitable for international transport through shipping by sea, by air or any other delivery method.
(Note: we can provide special packages according to buyer’s requirements.)
Delivery time
within 2weeks after payment, we will act fast and before shipment, we will provide product photo, packing photo to customer’s checking
Shipping method
---Express: UPS, FEDEX, DHL, TNT, EMS, etc
-Air shipping: Please choose your convenient shipping method according your detail requirement.
---Sea shipping: large quantity order
---Normally, it will take around 3--5days from China to destination country via air.
Payment
---T/T, Western Union, Paypal, or negotiable, ect.
