Rebar Detector and Covermeter , Rebar Scanner
Model:TBT-R660
Usage:
Testing the Location, distribution, direction, and diameter of the rebar and the thickness of concrete cover in concrete structure projects such as bridges, tunnels, walls etc. Detecting Ferro magnets in non-ferromagnetic media.
Evaluating the quality of construction
Evaluating the integrity and the durability of existing structures.
Testing the quantity of rebar when evaluating and developing the old structure
Testing the distribution and direction of electric cables and plumbing inside walls and floors.
Features
The host and the sensor is integrated, operation is conveniently and quickly;
The location of rebar, spacing, the thickness of the protective layer with screen display;
3.5 inch transflective color LCD screen are clearly visiblein in bright outdoor or indoor and in the dark;
The multi-coil design, faster speed, higher accuracy, stronger resolution;
The three-dimensional imaging function, can clearly reproduce measured steel distribution inside the body;
Chinese simplified, traditional Chinese, English, Japanese can freely switch.
Protective layer thickness range (mm) |
φ6~φ50 |
|
Max range(mm) |
First range |
1~80 |
Second range |
1~180 |
|
Max allowed error |
±1(mm) |
1~59 |
±2(mm) |
50~78 |
|
±4(mm) |
70~180 |
|
Applicable range(mm) |
φ6~φ32 |
|
Max allowed error for diameters measurement |
±1 |
|
Data correction |
Automatic |
|
---Carton box, wooden case or specified package
1) Inner package: dust-proof plastic bag
2) Outer package: standard export wooden case with pallet
3) Suitable for international transport through shipping by sea, by air or any other delivery method.
(Note: we can provide special packages according to buyer’s requirements.)
