concrete rebar locator and rebar corrosion detector
Model:TBT-R800
Usage
ZBL-R800 is a multi-functional integrated rebar detector which can be used for testing the thickness of protective layers, measuring the diameter, location, and distribution of rebar as well as for detecting the corrosion content of a rebar.
Feature
1.Unique all-wheel, dustproof and waterproof multi-parameter rebar probe ensures accuracy and reliability of data taking.
2. Rebar detection is automatically alerted by the probe via flashing red light.
3. The world’s first wireless onsite data transfer function, remote management also available.
4. Data can be stored on usb-thumb drive, great for field work.
5. The device can generate rebar distribution maps and rebar corrosion potential contour graphs.
6. Powerful professional analysis-process software allows for the automatic generation of test reports
Applicable range |
Diameter 6mm~50mm |
Corrosion detection method |
Single electrode |
Double electrode |
||
Protective layer thickness range (mm) |
First range |
Second range |
Measuring range |
±1000mV |
0~1000 mV |
|
3~98 |
3~196 |
Accuracy |
±1mV |
±1mV |
||
Maximum allowed error for protective layer |
±1 mm |
6~56 |
3~79 |
Tested points Interval X |
0~100 adjustable |
20 fixed |
±2 mm |
57~69 |
80~119 |
Tested points Interval Y |
0~100 adjustable |
0~100 adjustable |
|
±4 mm |
70~98 |
120~196 |
Power |
Built-in chargeable lithium battery |
||
Maximum allowed error for diameters measurement |
±1 rebar standard level |
Battery Time |
>38 hours |
|||
Data transmission |
wireless transmission |
Dimensions |
212mm´134mm´50mm |
|||
USB port |
thumb drive storage available |
Weight |
0.9kg |
|||
