RS-1616K(S) Pile Dynamic Measurement Instrument
I. Main Specification:
Product Model | RS-1616K(S) |
All-In-One Design | Yes |
Independent Work | Yes |
Controlling Module | Instrument exclusive IPC |
Display Mode | 640×480 LCD |
Sampling Interval | 12~32767μs adjustable continuously |
Sampling Resolution | 16 bit |
Floating-Point Enlargement | 1~64 times |
Fixed-Point Enlargement | 1X,10X,100X,1000X |
Sampling Length | 1k~8kbyte |
Trigger Mode | Channel trigger, outside trigger, sable trigger |
Memory Mode | 16M IDE-FLASH |
Opertion Mode | Photoelectric Knob |
Built-in Battery | High-energy Lithium Battery, it can work 6h |
Working Temp. | 0~40°C |
Power Supply | DC15V4A |
Dimension & Weight | 230×210×100mm,2kg |
Stable performance, best price, good quality , good after-sales service
Usage field: NDT product
Product name: RS-1616K(S) Pile Dynamic Measurement Instrument, China Pile Dynamic Measurement Instrument
