Ø 175 Type Disc Grinder Manganese steel pulverized Disc Crusher (TBT-175-I, TBT-175-II)
I. Usage
It is suitable for the laboratories of geological, metallurgical, chemical, building materials and other industrial departments and colleges and research institutes. It pulverizes the sample size less than or equal to 6mm, and the sample after crushing can be as fine as 120-200 mesh.
The equipment has a Ideal structure and can be continuously pulverized by feeding. There are two upright opposite grinding discs, one of which is fixed, and the other grinding disc rotates the sample, which is the first crushing equipment with excellent performance
Specification
|
Disc diameter (mm) |
φ175 |
|
Feed particle size(mm) |
≤6 |
|
Discharge granularity(mm) |
0.1 |
|
Crushing ability(Kg/hour) |
25 |
|
Output(Kg/hour) |
50~400 |
|
Motor(KW) |
1.1 |
|
Outside dimension (mm ) |
750*550*400 |
|
Weight(Kg) |
Around 100 |
