EVD Dynamic deformation modulus tester (Handheld drop hammer benkelman beams deflectometer)
Product Specification
| Test range | Applicable soil types | (Diameter of a quarter of all kinds of soil particle size is not greater than the load board and earth-rock mixture packing) |
| Test range | 100Mpa≤EVD≤225Mpa | |
| Test impact depth | 0-500mm | |
| Work environment | Temperature | |
| -10℃--40℃ | ||
| Humidity<90HR | ||
| Data acquisition device | Loading device | Weight:15Kg |
| Drop weight:10Kg | ||
| Maximum impact force:7.07KN | ||
| Impact duration:18±1ms | ||
| Loading plate | Weight:15Kg | |
| Diameter:300mm | ||
| Thickness:20mm | ||
| Handheld main engine | Subsidence test range | 0.10--2.00mm |
| Storage capacity | 2000 groups of test data | |
| Specifications | Screen size:3 inch | |
| Volume:100x205x40mm | ||
| Weight:0.8Kg | ||
| Power supply mode | The large capacity lithium battery, working time is more than 18 hours | |
| Printer | Connection method | Wireless bluetooth print |
| Packing specification | Main box | Material: Engineering plastics |
| Volume:385x300x175mm | ||
| Weight:4.5Kg | ||
| Outer packing | Material: Aluminum alloy | |
| Volume:1220x395x380mm | ||
| Weight:56Kg |
Detailed Features And Design
Suitable for the construction site, to determine the rock point load strength value
A ruler attach on the frame allow for direct measuring specimen diameter.
Features
- Used to determine moisture content of sand, soil and fine aggregate.
- The procedure involves the reaction between water and calcium carbide which when mixed together a gas is given off.
- The gas is directly proportional to the amount of water present in the sample and results in percentage moisture range 0-25% & 0-50%.
Our Service
- Installation and training
- If buyers visit our factory and check the machine, we will teach you how to installand use the machine, and also train your workers/technician face to face.
- Without visiting, we will send you user manual and video to teach you to install and operate.
- If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.
- After Service
- One year guarantee for whole machine.
- 24 hours technical support by email or calling
- If there is any problem found of the machine, we will repair it for free in one year.
Any questions, please contact me without hestitation, welcome your inquiry!Price can be negotiated
We can provide high quality products. OEM or OEM orders are also welcome.
Why Choose OBRK?
- Oubeiruike supply verious type of products,Test Molds, Concrete Mixer,Asphalt Tester,and Soil Road Lab Tester .... We assure high quality to you.
- All our products are made in China and with competitive price.Excellent quality with competitive price.We can offer OEM & ODM service.
Certificate
Packaging And Shipping
- Packaging Details Deval Abrasion Testing Machine is standard export wooden case.
- Port any port in china/Deval Abrasion Testing Machine
- We can deliver by sea at any port in china, and Also can ship by air via express company (door to door),it is quick and safe.
- We can ship By EMS,TNT,DHL and others ( door to door)
FAQ
Q:Are you trade company or factory?
A:We are trade company but we also have own factories. Building trade company is just for exporting various types of concrete mould and others products.
Q:Why your price is higher than others?
A:As we persist on that each factory should put quality at the first place. We spend time and money on developing how to make machines much more automatic, accurate and high quality. We can make sure that our machine could use more than ten years without any problem. We can provide one years free quality assurance.
Q:How to visit your company?
A:1. Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi (1 hour),then we can pick up you.
2.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then we can pick you up.
Hot Sale
|
|
|
All our products will be inspected thoroughly before shipping.Hope you will enjoy this shopping journey and we hope to have a long-time relationship with you. Welcome to visit our factory! Any questions please contact us, we will be of your service
LWEVD Dynamic deformation modulus tester (Handheld drop hammer benkelman beams deflectometer)
