Automatic Gauging Machines for Crankshaft, Crankshaft Measuring Machine
US$ 20,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Lee Power
Place of Origin:
Jiangsu, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Gauging Machines for Cylinder Block, Cylinder Block Measuring MachineUS$ 20,000 - 20,000MOQ: 1 Set -
Automatic Gauging Machines for Cylinder Head, Cylinder Head Measuring MachineUS$ 20,000 - 20,000MOQ: 1 Set
-
Air Micrometer Measuring SystemUS$ 645 - 645MOQ: 1 Set
-
Go No Go GaugesUS$ 645 - 645MOQ: 1 Set
-
High-precision Gas Momentum Meter Digital Air Pressure GaugeUS$ 645 - 645MOQ: 1 Set
Brand Name
Lee Power
Place of Origin
Jiangsu, China
Crankshaft measuring machine realizes the automatic measurements of the following items: out-of-roundness and cylindricity of main bearing and connecting rod neck; 4J width, connecting rod neck width, A-axis diameter, out-of-roundness and cylindricity; RF outer circle diameter and out-of-roundness; FIT outer cycle diameter; A-axis, B-axis and pulse plate keyway width. It also has the following functions: imprinting in accordance with grades, serial numbers imprinting, SPC analysis of the above measurement data, fast changes between different types, and data memory and saving.
Features
High measurement precision
High measurement accuracy
High measuring efficiency: 45 sec / piece
Greatly reduce labor costs
Specification
Measurement principle: Comparison measurement. Displacement sensor is used to measure the difference between the measured parts and the calibration parts, and then the relative sizes of the measured parts are calculated. The whole control system adopts Profinet bus communication mode for OPC communication with the host computer. The integration is strong and the communication is safe and reliable.
Measurement range: Manual adjustments for various sizes measurements. Centre-to-centre distance: 120mm-150mm, large bore inner diameter: 40mm-60mm, small bore inner diameter: 15mm - 30mm, big end thickness: 18mm-30mm.
Measurement takt time: ≤10 seconds, under normal condition and operation
Measurement position technology level: sensor resolution: 0.0001mm, measurement accuracy: ±0.001mm, GRR: ≤10%.
