Help CenterMDE-500 Programmable Electronic Micrometer
Related Products
-
Statistical Process Control WorkstationUS$ 5,000 - 5,000MOQ: 1 Set -
SPC SystemUS$ 5,000 - 5,000MOQ: 1 Set
-
Automatic Gauging Machines for Brake Disc, Brake Disc Measuring MachineUS$ 20,000 - 20,000MOQ: 1 Set
-
Hardware and Software for Data Collection and Process AnalysisUS$ 5,000 - 5,000MOQ: 1 Set
-
Automatic Gauging Machines for Connecting Rod, Comprehensive Measuring Machine for Connecting RodUS$ 20,000 - 20,000MOQ: 1 Set
Features
Extremely high stability
Highly integrated, no external buttons, operation and display integrated on the touch screen
MDE allows processing of measured value capability for various measuring applications.
One-touch master set operation and automatic master setting by panel key or input signals are utilized.
Max. of 12 measuring items are registered, no need to set parameters after selecting items.
Feedback signals can be put out to processing machine by UCL/LCL quality control graphical display
Pre-set counters are ready for count up output of NG repeat, selecting counter, classifies counter, etc.
The detector uses high precision and a good linear differential transformer, so very slight change can be detected with high reliability.
Any size measuring head can be configured
Micrometer can be customized with roundness, minimum, maximum, average measurement
Closed structure with waterproof and oil-proof. Suitable for harsh industrial environments.
10 sets of programs can be set up on site to carry out measurements of various specifications. One-click product switching.
Independent air source control box to ensure that the inside of the instrument is dry and has a longer service life
Micrometer can store 100,000 measurement data, power loss data is not lost
Automatically save with delay and send test data
7 inches TFT LCD screen for easy programming
Specifications
|
Item |
MDE-500 Programmable Electronic Micrometer |
|
Channel |
2-12 channels |
|
Number of workpieces memorized |
max. 12*as requested |
|
Operation |
Enable to set up optionally according to measuring requirement like circularity, cylindricity, max/min value, etc. |
|
Measurement function |
Inner diameter, outer diameter, thickness, highness, taper, straightness, verticality, concentricity, cylindricity, flatness, center distance, parallelism, torsion, bounce, position, fitting gap, airtightness, etc. |
|
One-touch calibration |
Easy calibration (magnification or drift control) by one-touch operation start, etc. |
|
NC feedback function |
Compensated +/- signal by UCL/LCL quality control graphical display (by repeat counter, with count cancelled function after feedback) |
|
Workpiece counter |
Count of number measured |
|
Power |
100~240V±10% 50/60Hz 11VA |
|
Dimension |
260mm(W)*280mm(H)*200mm(D) |
|
Weight |
6 kg |
|
Option |
Audible alarm, USB, Air auto shut off, Wireless transmission, QR code with measurements, Statistics operation, Extension of channel, etc. |
Performance
|
Items |
Standard Performances |
||||
|
Measuring range |
5µm |
10µm |
25µm |
50µm |
100µm |
|
Display resolution |
0.1µm |
0.2µm |
0.5µm |
1.0µm |
2.0µm |
|
Max. measuring error |
0.2µm |
0.4µm |
1.0µm |
2.0µm |
4.0µm |
|
Repeatability |
0.1µm |
0.2µm |
0.5µm |
1.0µm |
2.0µm |
|
Response time |
Max 1.2s |
||||
