Home > Instruments & Meters > Analysis Instrument > Gas Analyzer > Vegetable and Fruit Drying Equipment
US$ 100,000 - 200,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Drawell
Place of Origin:
Shanghai, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Small Scale Production Vacuum Vertical Lyophilizer EquipmentUS$ 1,200 - 4,000MOQ: 1 Piece -
Low Price Lab LyophilizerUS$ 1,790 - 1,790MOQ: 1 Piece
-
High Quality Lab Freeze Dryer for SaleUS$ 2,000 - 3,000MOQ: 1 Piece
-
DW-18ND Electric Heating Freeze-Drying MachineUS$ 6,000 - 7,000MOQ: 1 Piece
-
Drawell Lab Freeze Dryer Machine With PriceUS$ 2,037 - 2,057MOQ: 1 Piece
Brand Name
Drawell
Place of Origin
Shanghai, China
| Vegetable freeze-drying machine Features, 1,The interior of the machine is made of stainless steel, which meets the requirements of high standard products. 2,Shelf refrigerator ≤-50℃,Cold trap refrigerator ≤-60℃.(Excluding radiation) 3,R404a environmental refrigeration, international brand high efficiency screw compressor. 4,The plate has a constant temperature function in the process of refrigeration and sublimation. 5,The high efficiency vacuum pump combined with the roots pump,which has the function of oil and water separation. 6,With high efficiency capture water trap and fast frost function. | |||||||||||||||
| Parameters | unit | Traditional Heating Mode | Radiation heating mode | ||||||||||||
| FD-CG10 | FD-CG15 | FD-CG20 | FD-CG35 | FD-CG50 | FD-CG75 | FD-CD50 | FD-CD75 | FD-CD100 | FD-CD125 | FD-CD150 | FD-CD200 | ||||
| Capacity | Drying Area | m2 | 10 | 15 | 20 | 35 | 50 | 75 | 54.4 | 75.7 | 100.9 | 126.1 | 150.3 | 204.3 | |
| Condenser capacity | kg/B | 200 | 300 | 400 | 700 | 1000 | 1500 | 1000 | 1500 | 2000 | 2500 | 3000 | 4000 | ||
| Specs | Cylinder | Diameter | mm | 1300 | 1300 | 2000 | 2000 | 2200 | 2200 | 2200 | 2200 | 2200 | 2600 | 2600 | 2600 |
| Length | mm | 2230 | 3010 | 2350 | 3300 | 3650 | 4650 | 7570 | 9770 | 11620 | 13000 | 13580 | 16100 | ||
| Shelf size | Width | mm | 600 | 600 | 1000 | 1000 | 1000 | 1000 | 540 | 540 | 540 | 540 | 580 | 580 | |
| Length | mm | 1520 | 2300 | 1250 | 2200 | 2500 | 3750 | 3280 | 4880 | 6680 | 6520 | 7120 | 9720 | ||
| the distance between shelf | mm | 70 | 76 | ||||||||||||
| Shelves | No | 11+1 | 11+1 | 16+1 | 16+1 | 20+1 | 20+1 | 17*2 | 17*2 | 17*2 | 21*2 | 21*2 | 21*2 | ||
| Shelf temperatuer range | ℃ | -40~+90 | -50~+90 | RT-120℃ | |||||||||||
| Shelf temperature difference | ℃ | ±3 | ≤±3℃ | ||||||||||||
| Minimum temperature of cold trap | ℃ | -50 | -60 | ≤60℃ | |||||||||||
| Ultimate vacuum degree | Pa | 5 | 13 | 13.3Pa | |||||||||||
| Basic supply | Cooling water | m³/hr | 12 | 17 | 21 | 25 | 36 | 34+6 | 45+8 | 52+10 | 82+10 | 90+15 | 106+20 | ||
| Compressed air volume | l/min | Compressed air volume | |||||||||||||
| Compressed air volume | m³/B | 0.035 | 0.053 | 0.071 | 0.125 | 0.178 | 0.267 | 0.18 | 0.27 | 0.36 | 0.45 | 0.53 | 0.71 | ||
| Defrosting water | m³/hr | 0.5 | 0.7 | 1 | 1.6 | 2.3 | 3.5 | / | |||||||
| Installation Power | kw | 40 | 50 | 70 | 120 | 140 | 200 | 75+12 | 100+19 | 160+23 | 195+30 | 270+36 | 315+45 | ||
| External dimensions | Length | mm | 2300 | 3100 | 2400 | 3300 | 3700 | 5000 | 7600 | 9800 | 12000 | 13000 | 136000 | 161000 | |
| Width | mm | 2000 | 2000 | 2700 | 3400 | 3400 | 3400 | 9100 | 7000 | 4700 | 5000 | 5000 | 6000 | ||
| Height | mm | 2000 | 2000 | 2500 | 2500 | 2500 | 2500 | 5000 | 5000 | 5000 | 5500 | 5500 | 5500 | ||
| Nominal area | m2 | 10 | 15 | 20 | 35 | 50 | 75 | 50 | 75 | 100 | 125 | 150 | 200 | ||
