RVDV-1 Digital Viscometer
.The main technical indicators
Measuring Range(mPa·s) |
80~40,000,000 |
|
Rotating Speed (RPM) |
0.1 ~ 99.9 (Stepless Gear) |
Number of Spindles |
Spindles (Code R2,R3,R4,R5,R6,R7) are equipped with the product |
Accuracy |
±1% full scale range in use |
Repeatability |
±0.5% full scale range in use |
Readability |
1.when viscosity is lower than 10.0 cp : 0.01 2.when viscosity is lower than 10000 cp : 0.1 3.when viscosity is equal or higher than 10000 cp : 1 |
Power |
|
LCD screen display |
The LCD screen can display the viscosity, speed, torque spindle, temperature and the maximum viscosity can be measured in the current spindle speed value. |
.Apparatus to be equipped
. digital viscosity meter |
1 pce |
· ascending and falling rack |
1 set |
. standard spindle |
1 set |
· power adapter |
1 pce |
· protective frame of spindle |
1 pce |
· spanner |
1 pce |
· Seat and leveling feet |
1 set |
. RS232 standard output interface |
1 pce |
. RTD temperature probe |
1 pce |
|
|
.Options
·Extreme low viscometer adapter (with one spindle L0) |
·Small sample adapter (with spindle 21, 27, 28 and 29 each) |
·Temperature-controlled heater (with spindle 21, 27, 28 and 29 each) |
·Spindle R1 |
·Special software that can complete the function in collecting the data automatically utomatically |
·DV program control download software |
·Specially used printer |
