Double Acting Hydraulic Power Pack Unit 220V AC

General Description
Equipped with the zero leakage double-check solenoid valves, this power unit fulfils the complete separation of the two independent circuits,which are respectively for the main platform and subordinate platform of the double scissors lift. By increasing the number of the solenoid vavles, it is easy to get more independent circuits, which are used to control the corresponding cylinders.

Features:

1. The hydraulic power units are offered for industrial, mining, water conservancy, agriculture, electric power, machine tool and construction applications.

2. Standard, compact and custom power units are available.

3. Electric control system (wire or wireless type) is optional.

4. Any kind and size of hydraulic cylinder to matching the system is optional.

5. Hydraulic power units consisting of pumps, reservoirs, relief valves, filters, sight gages, and filler breathers deliver reliable power for hydraulic systems.

power pack consists of high pressure gear pump,AC motor,integrated block,hydraulic valves,oil tank assemble.

power pack consists of high pressure gear pump,AC motor,integrated block,hydraulic valves,oil tank assembly.Specially designed for plate of lift with the function of power lift and gravity lowering.When solenoid valves is elctric,lifting dropped off,flow control valves make the lowering constant speed.

Parameters:

Special notes
  1. The power unit is of S3 duty, which can only be worked intermittently, ie., 1minute on and 9 minutes off.
2. Clean all the hydraulic parts concerned before mounting the power unit.
3. Viscosity of the hydraulic oil shoud be 15~68 cst, which should also be clean and free of impurities. N46 hydraulic oil is recommended.
4. This power unit should be mounted vertically.
5. Check the oil level in the tank after the first start of the power unit.
6. Change the oil after the first 100 hours of running the power unit, then change the oil every 3000 hours.
7. We are at your disposal to offer you the power units with your favorite power, flow, pressure as well as the tank capacity.

1,sample service: samples can be provided.

2,customized services: a variety of motors can be customized according to customer demand.

3, aftermarket service: according to consumer requirements, technical guidance on the use and other aspects. In case of quality problems under normal use, free replacement within one year of free maintenance for life.

1. Business Type

a. Manufacturer located in Wuxi City, Jiangsu Province
b. Factory cover an area of 6000 square meterselectric forklift motor
c. Employees: over 70 in office & workshops

2. Certificates

CE, ISO9001 etc

3. How long could we get the goods?

a. 10-20days for mass production based on your quantity
b. 5~10days for Sampe orders

4. Quality Control

a. 100% inspection before packing electric forklift motor
b. Spot inspection before shipment
