Home > Electrical & Electronics > Electric Motor > DC Motor > Chinese Factory High Quality Hydraulic Lifting Column
US$ 1,000 - 1,200
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Jinle
Place of Origin:
China
Model Number:
lifting column
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Chinese Factory XQD-3C Direct Drive Motor 24V 3.5KWUS$ 100 - 140MOQ: 1 Piece -
24V 2KW Chinese Factory Direct Sale High Torque dc Pump Motor ZD2931US$ 39 - 51MOQ: 1 Piece
-
Factory Direct Sale Hydraulic Pump DC Motor 24V 3HP 2700RPMUS$ 35 - 50MOQ: 1 Piece
-
Factory Direct Sale 12V DC Motor Used For Tennis Ball MachineUS$ 36 - 39MOQ: 1 Piece
-
48V 4KW Chinese Factory High Quality High Torque dc Electric Motor Forklift ZD4873AUS$ 85 - 100MOQ: 1 Piece
Brand Name
Jinle
Place of Origin
China
Model Number
lifting column
Certification
CE
Torque
3NM
Usage
Boat, Car, Electric Bicycle, Fan, Home Appliance
Construction
Series Wound
Efficiency
IE 4
Protect Feature
Drip-proof
Continuous Current(A)
Current
Commutation
Brush
Main technical parameters:
1. System control: integrated electric hydraulic drive
2. Minimum passing pressure: it can pass through container cars of 80-120 tons or less.
3. Rated voltage: AC220V 50Hz.
4. System power (W): 350W.
5. Rise time: ≤ 3-4s
6. Descent time: ≤ 3-4s
7. Working temperature: - 35 ℃ ~ 75 ℃ (suitable).
8. Storage environment: - 10 ℃ ~ 65 ℃, rain proof, moisture-proof and dust-proof.
9. Material: 304 stainless steel
10. Height of lifting column: 600mm
11. Standard thickness: 6, 8, 10, 12, 15, 30mm (optional)
12. Diameter selection: 168, 219, 273mm (optional)
13. Box size: 520 * 520 * 1130 / 430 * 430 * 1130 (optional)
14. Internal structure: with load-bearing steel beam column, anti-collision steel beam column, 4 navigation poles
15. Integrated motor core: stroke: 600mm, outer diameter of oil cylinder: 60mm, rod diameter: 16mm
16, 6K mirror cylinder
17. LED lamp (acrylic lamp ring)
18. Two reflective films
19. Linkage interface
20. It can be manually lowered in case of power failure
22. Protection grade: IP68
23. Weight: 150 ± kg
24. Reverse operation can be carried out according to requirements during ascending and descending
25. Noise during operation of the device ≤ 60dB
26. Waterproof integrated hydraulic drive
27. The hydraulic cylinder is double sealed to ensure the waterproof level
28. Hydraulic drive with hydraulic lock
29. PLC control programming command control system
30. 220V power switch
31. Control solenoid valve 24V
32. Remote control range 50m-100m (according to the environment)
33. The display text of the control box can be adjusted (up, down, start, time control and adjustment)
34. Display text in both Chinese and English
35. PLC built-in encryption system
Product Description
1. Business Type
a. Manufacturer located in Wuxi City, Jiangsu Province
2. Certificates
CE, ISO9001 etc
3. How long could we get the goods?
a. 10-20days for mass production based on your quantity
b. 5~10days for Sampe orders
4. Quality Control
a. 100% inspection before packing electric forklift motor
b. Spot inspection before shipment
a. Manufacturer located in Wuxi City, Jiangsu Province
b. Factory cover an area of 6000 square meterselectric forklift motor
c. Employees: over 70 in office & workshops 2. Certificates
CE, ISO9001 etc
3. How long could we get the goods?
a. 10-20days for mass production based on your quantity
b. 5~10days for Sampe orders
4. Quality Control
a. 100% inspection before packing electric forklift motor
b. Spot inspection before shipment
