800W Permanent Magnet Electric Wheelchair Motor DC 24V

800W Permanent Magnet Electric Wheelchair Motor DC 24V thumbnail-1
800W Permanent Magnet Electric Wheelchair Motor DC 24V thumbnail-2
800W Permanent Magnet Electric Wheelchair Motor DC 24V thumbnail-3
800W Permanent Magnet Electric Wheelchair Motor DC 24V thumbnail-4
800W Permanent Magnet Electric Wheelchair Motor DC 24V thumbnail-5
800W Permanent Magnet Electric Wheelchair Motor DC 24V thumbnail-6
800W Permanent Magnet Electric Wheelchair Motor DC 24V thumbnail-7
800W Permanent Magnet Electric Wheelchair Motor DC 24V photo-1
800W Permanent Magnet Electric Wheelchair Motor DC 24V photo-2
800W Permanent Magnet Electric Wheelchair Motor DC 24V photo-3
800W Permanent Magnet Electric Wheelchair Motor DC 24V photo-4
800W Permanent Magnet Electric Wheelchair Motor DC 24V photo-5
800W Permanent Magnet Electric Wheelchair Motor DC 24V photo-6
800W Permanent Magnet Electric Wheelchair Motor DC 24V photo-7
US$ 30 - 40 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
JINLE
Place of Origin:
Jiangsu, China
Model Number:
M208XXN
Contact Supplier Request Quote Chat Now
Wuxi Jinle Automobile Motor Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name JINLE
Place of Origin Jiangsu, China
Model Number M208XXN
Certification CE
Torque 2N.m
Usage Boat, Car, Electric Bicycle, Fan, Home Appliance
Construction Series Wound
Efficiency IE 4
Protect Feature Drip-proof
Continuous Current(A) Current
Speed(RPM) 3200RPM
Commutation Brush

800W Permanent Magnet Electric Wheelchair Motor DC 24V

800W Permanent Magnet Electric Wheelchair Motor DC 24V

Product Description

Features:

100% copper wire

stable running, high efficiency, low noise

good service after sale

12V, 24V, 48V, 60V etc.  on your request

Customized production is available!

Supply for OEM Production!

nearly 20 years' manufacturing experience



Specification:

1) Type: M208XXN

2) Voltage: 24V

3) Power: 0.8KW

4) Speed: 3200PM

5) Rotation: CW

6) O.D. : 80mm

7) Operating mode: S3

8) Insulation Class: F

9) Protection Degree: IP 54

10) Torque: 2N.m

11) Weight: 2.5KG

 800W Permanent Magnet Electric Wheelchair Motor DC 24V800W Permanent Magnet Electric Wheelchair Motor DC 24V800W Permanent Magnet Electric Wheelchair Motor DC 24V

Parameter for Motor DC 24V

Unload

Speed

5091 RPM

Current

10.230 A

Max_Torque

Torque

2.670 N.m

Current

64.340 A

Speed

3639 RPM

Efficiency

66.35%

Output Power

1017.40 W

Max_Efficiency

Efficient

69.36%

Speed

4016 RPM

Torque

1.770 N.m

Current

44.200 A

Output Power

744.30 W

Max_Pout

Efficiency

66.35%

Speed

3639 RPM

Torque

2.670 N.m

Current

64.340 A

Output Power

1017.40 W

 800W Permanent Magnet Electric Wheelchair Motor DC 24V

800W Permanent Magnet Electric Wheelchair Motor DC 24V

800W Permanent Magnet Electric Wheelchair Motor DC 24V800W Permanent Magnet Electric Wheelchair Motor DC 24V800W Permanent Magnet Electric Wheelchair Motor DC 24V800W Permanent Magnet Electric Wheelchair Motor DC 24V800W Permanent Magnet Electric Wheelchair Motor DC 24V800W Permanent Magnet Electric Wheelchair Motor DC 24V
