24v dc Motor 4kw High Speed High Torque Jinle ZD2973A

24v dc Motor 4kw High Speed High Torque Jinle ZD2973A thumbnail-1
24v dc Motor 4kw High Speed High Torque Jinle ZD2973A thumbnail-2
24v dc Motor 4kw High Speed High Torque Jinle ZD2973A thumbnail-3
24v dc Motor 4kw High Speed High Torque Jinle ZD2973A thumbnail-4
24v dc Motor 4kw High Speed High Torque Jinle ZD2973A thumbnail-5
24v dc Motor 4kw High Speed High Torque Jinle ZD2973A photo-1
24v dc Motor 4kw High Speed High Torque Jinle ZD2973A photo-2
24v dc Motor 4kw High Speed High Torque Jinle ZD2973A photo-3
24v dc Motor 4kw High Speed High Torque Jinle ZD2973A photo-4
24v dc Motor 4kw High Speed High Torque Jinle ZD2973A photo-5
US$ 110 - 120 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Jinle
Place of Origin:
Jiangsu, China
Model Number:
ZD2973A
Contact Supplier Request Quote Chat Now
Wuxi Jinle Automobile Motor Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Jinle
Place of Origin Jiangsu, China
Model Number ZD2973A
Certification CE
Torque 13N.m
Usage Boat, Car, Electric Bicycle, Fan, Home Appliance
Construction Shunt Wound
Efficiency IE 4
Continuous Current(A) Current
Speed(RPM) 3100rpm
Commutation Brush

24v dc motor 4kw high speed high torque Jinle ZD2973A

Product Description



Specifications of hydraulic dc motor 24V :



Model

 Material VOLTAGE POWER SPEED    ROTATION DIRECTION    O.D
 ZD2973A 100% copper wire  24V  4.0KW 3100rpm   CW  114mm




24v dc motor 4kw high speed high torque Jinle ZD2973A

For more choices, please see our latest catalog!

Customized production is available! !

Send me the parameters, we will customize for you!!!

DC motor for pump /oil pump / oil pressure
DC motor for power unit / power pack / hydraulic power unit / hydraulic power pack / HPU
DC motor for automation
DC motor for lift / lifting equipment / liftgate / tail lift / forklift / lift truck
DC motor for forklift truck / fork truck / tailgate
DC motor for tip truck / truck / lorry
DC motor for tipper trailer / dump Truck / tipper
DC motor for hydraulic parts
DC motor for garbage truck /dustbin lorry/ waste collection vehicle /refuse collection vehicle
DC motor for winter service vehicle / snow removal vehicle
DC motor for tractor
DC motor for mechanical equipment / hospital bed / hospital cot
DC motor for agricultural machinery / farm machinery
DC motor for industrial machinery
DC motor for construction
DC motor for muck truck

DC motor for jack



Packaging & Shipping

24v dc motor 4kw high speed high torque Jinle ZD2973A

Certifications

24v dc motor 4kw high speed high torque Jinle ZD2973A24v dc motor 4kw high speed high torque Jinle ZD2973A

Our Services

1) Low noise
2) Easy brush replacement
3) OEM service avaliable
4) Efficient and long continuous running time

5) Customization available

6) Robust construction for long and reliable service life
7) 100% copper wire

8) 12V, 24V, 36V, 48V,60V,72V as per customers' option

9) Factory established in 1996 with nearly 20 years' manufacturing experience





24v dc motor 4kw high speed high torque Jinle ZD2973A



Company Information
Our factory was established in 1996,  professional in forklift motors, hydraulic power unit motors.



We have nearly 20 years' manufacturing experience with a strong team of 30 engineers for development and research. The motors' annual output has been more than 200,000 sets.



So far, we are the only designated OEM hydraulic power unit motor supplier in China for US WAI Company, OEM forklift motor supplier for Korea SOOSUNG. Also, we cooperated Korea KOPACK and HELI in China.



We have been attentively persisting in manufacturing motors for 20 years.

24v dc motor 4kw high speed high torque Jinle ZD2973A
 24v dc motor 4kw high speed high torque Jinle ZD2973A
Application

24v dc motor 4kw high speed high torque Jinle ZD2973A

FAQ

1. Business Type

a. We are a factory, located in Wuxi City, Jiangsu Province, near Shanghai and Nanjing
b. Factory cover an area of 6000 square meters

c. Employees: over 80 in office & workshops



2. Certificates

CE, ISO9001 etc.



3. How long could we get the goods?

a. 10-20 days for mass production based on your quantity
b. 5~10 days for Sampe orders



4. Quality Control

a. 100% inspection before packing

b. Spot inspection before shipment



If you need catalog , pls no hesitate to ask:

QQ: 120731381

Wechat:phoenix05222

MOB/skype: +86 15358018419
