Home > Products > Hydraulic dc motors > ZD1201 Hydraulic DC Motor 12V 1.6KW With CW Rotation
ZD1201 Hydraulic DC Motor 12V 1.6KW With CW Rotation
- SHANGHAI
- T/T Credit Card
You May Like
Product Details
| Brand Name | Jinle | Place of Origin | Jiangsu, China | |
| Model Number | ZD1201 | Type | Micro Motor | |
| Certification | CE | Torque | 6NM | |
| Usage | Boat, Car, Electric Bicycle, Fan, Home Appliance | Construction | Series Wound | |
| Efficiency | IE 4 | Protect Feature | Drip-proof | |
| Voltage(V) | 12V | Output Power | 1.6KW | |
| Continuous Current(A) | 120A | Speed(RPM) | 2500RPM | |
| Commutation | Brush |
Product Description
ZD1201 Hydraulic DC Motor 12V 1.6KW With CW Rotation
We will attend HANNOVER MESSE in 2017 in German, BOOTH No A30-19 . From April 24th-28th.
Welcome your visit!
Specification:
1. Type: ZD1201
2. Voltage: 12V
3. Power: 1.6KW
4. Speed: 2500RPM
5. Rotation: CW
6. O.D. : 114mm/4.5'
7. Insulation: F
8. Protection Class: IP54
9. Operation Mode: S3
10. Color: Customized
Feature:
stable running
high efficiency
low noise
12V, 24V, 48V, etc. on your request
Customized production is available!
Customized color and package is accepted!
Supply for OEM Production!
nearly 20 years' manufacturing experience
We are OEM manufacturer of WAI Group!
| 1259 | 12V | 50W | 500RPM | CW | 56mm | 0.5N.m | S2 |
| N2463 | 24V | 200W | 3000RPM | BI-DIRECTIONAL | 63mm | 1N.m | S1 |
| ZDY1256 | 12V | 200W | 3000RPM | BI-DIRECTIONAL | 56mm | 1N.m | S3 |
| ZDY211 | 24V | 0.8KW | 3650RPM | CW | 80mm | 2N.m | S3 |
| ZDY212 | 24V | 0.5KW | 2800RPM | CW | 80mm | 2N.m | S3 |
| ZDY112 | 12V | 0.5KW | 2300RPM | CW | 80mm | 2N.m | S3 |
| ZDY113 | 12V | 0.8KW | 3500RPM | CW | 80mm | 2N.m | S3 |
| ZDY118 | 12V | 1.2KW | 3000RPM | CW | 80mm | 2N.m | S3 |
| ZDY218 | 24V | 1.2KW | 3000RPM | CW | 80mm | 2N.m | S3 |
| ZDY418 | 48V | 800W | 3000RPM | CW | 80mm | 2N.m | S3 |
| ZDY618 | 60V | 800W | 3000RPM | CW | 80mm | 2N.m | S3 |
| MA08XXN | 12V | 0.8KW | 3200RPM | BI-DIRECTIONAL | 80mm | 2N.m | S3 |
| MB08XXN | 24V | 0.8KW | 3000RPM | BI-DIRECTIONAL | 80mm | 2N.m | S3 |
| M108XXN | 12V | 0.8KW | 3200RPM | BI-DIRECTIONAL | 80mm | 2N.m | S3 |
| M208XXN | 24V | 0.8KW | 3000RPM | BI-DIRECTIONAL | 80mm | 2N.m | S3 |
| ZDY211S | 24V | 0.8KW | 3100RPM | CCW | 80mm | 2N.m | S3 |
| ZDY113S | 12V | 0.8KW | 3200RPM | CCW | 80mm | 2N.m | S3 |
1) Low noise
2) Easy brush replacement
3) OEM service avaliable
4) Efficient and long continuous running time
5) Customization available
6) Robust construction for long and reliable service life
7) 100% copper wire
8) 12V, 24V, 36V, 48V,60V,72V as per customers' option
9) Factory established in 1996 with nearly 20 years' manufacturing experience
Other models you maybe interested in:
You can click on the picture then have a detailed description:
Permanent Magnet Motors Direct drive motors:
pallet truck hydraulic power units : vechicle tail gate power unit
1. Business Type
a. Manufacturer located in Wuxi City, Jiangsu Province
b. Factory cover an area of 6000 square meterselectric forklift motor
c. Employees: over 70 in office & workshops
2. Certificates
CE, ISO9001 etc
3. How long could we get the goods?
a. 10-20days for mass production based on your quantity
b. 5~10days for Sampe orders
4. Quality Control
a. 100% inspection before packing electric forklift motor
b. Spot inspection before shipment
