High Quality 55m Max Head 4m3/h Max Flow dc Submersible Solar Water Pump for Bore and Irrigation EMP524

Profile

Adopt stainless steel screw and stator, permanent Magnet Brushless motor. With combination of motor and controller, the max efficiency is ever 85%, raises 25% than the traditional AC one.

Material:

(A) Stainless steel casing, shaft core, coupling and pump body; copper alloy connecting, base; rubber stator of high-strength and wear-resistant.

(B)Oil immersion style stainless steel submersible motor.

Product Feature:

(A)Compact structure, high-lift, noiseless, pollution-free; complete electrical protecting controller device, against under-voltage, over-voltage, over-flew, overload, waterless etc.; automatic recovery; controlling water height as demand.

(B)Easy installation, maintenance-free, safe and reliable.

Max Head: 55m   Max flow: 4m3/h

Application:

These electric pumps series are workable within maximum head, as there are no restrictions of BDC. With the addition of high head, high efficiency and wide high efficiency zone, they are suitable for distance water irrigation, high efficiency of increasing oxygen on aquaculture, pumping water from deep well, gardening, fountain and etc.

Working condition:

(A)Non-corrosive water; the volume ratio of sand content no more than 1‰; particle size less than 0.2 mm.

(B)Max medium temperature up 10+40℃; PH value remains 6.5-8.5.

(C)Work close to the rated head and must be immersed in water.
