Product:brushless high torque dc motor 12v 100 nm bldc
Product Application: Outdoor advertising, medical equipment, logistics transmission, mechanical equipment, solar tracking device, precision equipment etc.
SPECIFICATIONS |
| Model | Voltage (VDC) | Speed (RPM) | Rated Torque (g.cm) | Power (W) | Weight (kg) | Length (mm) |
| BMM777 | 12 | 4000 | 120 | 5 | 0.15 | 40 |
General Specifications
| Item | Specification |
| Winding Type | Star/Delta |
| Hall effect angle | 120 degree electric angle |
| Shaft runout | 0.03mm |
| Radial play | 0.03mm/50g |
| Axial play | 0.03mm/50g |
| Max radial force | 35N/20mm from the flange |
| Max axial force | 30N |
| Insulation class | Class B |
| IP class | IP40 |
| Dielectric strength | 500VDC for one minute |
| Insulation resistance | 100MΩmin 500VDC |
Electric Connection
| Lead NO. | Lead color | Lead Gauge | Function | Description |
| 1 | Red | UL3266/28AWG | VCC +5VDC | supply voltage for hall sensors |
| 2 | Black | UL3266/28AWG | GND | ground for hall sensors |
| 3 | Yellow | UL3266/28AWG | HALL A | signal of hall A |
| 4 | Green | UL3266/28AWG | HALL B | signal of hall B |
| 5 | Blue | UL3266/28AWG | HALL C | signal of hall C |
| 1 | Yellow | UL3266/22AWG | PHASE U | motor phase U |
| 2 | Green | UL3266/22AWG | PHASE V | motor phase V |
| 3 | Blue | UL3266/22AWG | PHASE W | motor phase W |
OUTLINE DRAWING |
SIMILAR PRODUCT |
Similar Torque | | | |
|
| |
| BMM766 | BMM779 | BMM920 |
|
|
|
Each motor is packed in a foam box, 3pcs in a carton and 45 cartons in a pallet. If you have any special needs, please let us know, we can design packaging according to your request.
McMaster Electrics Co., Ltd is a professional company specializing in electrical and mechanical products, providing expert solutions and technical support. Our products include electrical motors, gear and gearboxes, transmissions and drive solution, HVAC fan/blower, controllers, pumps and relative components. We have been a reliable business partner for our North American and European customers since 2001. We provide high quality electrical motor, gearbox, fan/blower, controller, pump, ect. We also provide expert solutions and technical support to help your projects to be more competitive and successful. We have Headquarter and sales/service office in US, technical support/service company in China, Joint Ventures in Changzhou area and long term strategic manufacturing partners all over China. Contact us for your inquiry and you will have a pleasant and satisfied experience working with us in return.
1. Q: Can you provide detailed technical data and drawing?
A: Yes, we can. Please tell us which product you need and the applications, we will send the detailed technical data and drawing to you for your evaluation and confirm.
2. Q: Can I visit your factory before we place an order?
A: Yes, you are welcome to visit our factory. We are very pleased if we have the chance to know more about each other.
3. Q: How to control the products quality in your company?
A: With professional quality team, advanced product quality planning, strict implementation, continuous improvement, the quality of our products is well controlled and consistent.
