Home > Products > Swivel Joint > Both end are thread connection stainless steel 304 high pressure water rotary union for tower crane spray system
Both end are thread connection stainless steel 304 high pressure water rotary union for tower crane spray system
- 10000 Piece / Pieces per Month
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
- 15 days
- Deublin rotary joint alternative products JY-155-000-001
- Deublin rotary joint alternative products JY-255-000-002
- Deublin rotary union alternative products JY-255-052-255043
- Deublin rotary union alternative products JY-525-000-054255
- Both end are thread connection stainless steel 304 high pressure water rotary joint for tower crane spray system
- BSP thread connection stainless steel 304 high pressure high speed rotary union for hydraulic oil,water
Product Details
Brand Name: | Jieyi | Place of Origin: | China | Model Number: | JYSW02-25A stainless steel rotary union |
Material: | Stainless Steel | Type: | Flange | Shape: | Other, Round |
Technics: | Forged | Connection: | Flange | Head Code: | Other, Round |
Product Description
Both end are thread connection stainless steel 304 high pressure water rotary union for tower crane spray system
Swivel joint can work with elbow head and corner parts to form rotary pipelines with different structures. By using high-pressure and abrasion resistant sealing ring and high-precision support structure, the rotary unions for molten salts feature high efficiency, low leakage and corrosion resistance. According to the properties of media, various raw materials are available.
Use parameters | |
Pressure | 450 bar / 45 MPa |
Temperature | 260 ℃ / 500 °F |
Speed | 100 rpm |
Media | Water, Gas, Oil |
Size | 3/4'' ~ 20''; or customized |
Connection | Flange |
Standard | DIN, ANSI, JIS |
Seal | Imported seal |
Bearing | NSK, SKF, HRB |
Material | SS304 / Carbon steel |
Process treatment | Carbonitriding |
Application range of rotary joint:
Swivel joints are widely used in the connection between pipelines in the tower crane spray system, petroleum industry, natural gas industry, hydraulic equipment, solar power generation and other industries.
Features:
JYSW-02 type rotary joint is specially used for reciprocating or low-speed rotating movement of fluid medium between steel pipes. It has high wear resistance, flexible rotation and strong support ability. The seal adopts imported customized seal. Has reliable sealing performance.
Product show
Company Profile
Certificate
Delivery
Product packaging
Warehouse corner
Why choose us
1.Always Innovating
We have accumulated rich experirence in producing Rotary Joint,advanced equipment,advanced technology,professional staff.we keep on Innovating all the time.
2.Design Concept
Reasonable design, advanced structure,superior quality,long service life.
3.Reliable Quality
We are Alibaba Assessed Supplier,our products are certified by ISO9001,CE etc.
4.Short leading time
We have professional and advanced machines.we have 4 production line,can produce production quickly.
5.Good Price
We are crontroling each part cost so we can give customers the competitive price.
6.Internal Control
Internal inspection,all our products must be checked 3 times before packing.
7.Prompt Reply
We’ll reply your enquiry within 2 hours.
Contact us
If you have any needs, please feel free to contact us. We can produce according to your samples or drawings, we can also customize the design drawings for you according to your requirements, and then send them to you for confirmation!
