HZ-3110 Transformer DC Resistance Meter
Transformer winding DC resistance test is a transformer in the transfer, overhaul and change the essential experimental projects tap.Project is also important to check after transformer failure.
Features
l Output current is large, measurement ranges wide,small size, light weight, simple operation.
l Test speed, high precision, retest good, strong anti-jamming capability.
l With perfect protection circuit, high reliability.
l Sound the alarm function with discharge,clear discharge instructions,reduce misuse.
Parameters
Output Current 10A,5A,1A
Measurement Range 10A:1mΩ~2Ω
5A:1mΩ~4Ω
1A:10mΩ~20Ω
Resolution: 1μΩ
Dimensions 350mm*216mm*226mm
Accuracy: ±(0.2%+2words)
Instrument weight 8kg
Usage conditions:
Ambient temperature -10℃~50℃
Operating power AC220V±10%
Humidity ≤85%RH
Power frequency 50±1Hz
From the date of purchase within one year instrument, is a product quality problem free repair replacement, lifetime supply of maintenance and technical services. The instrument has found anomalies or malfunctions please contact us to arrange the most convenient treatment options.
HuaZheng Electric Manufacturing (Baoding) Co.,Ltd is founded in 2008,the supplier of the State Grid in China.It means we are the supplier of the Chinese Government.And our products spread throughout the whole China.
Our main products : Insulation Oil Tester, Cable Fault Locator, High Voltage Generator,transformer tester, relay protection tester,insulation resistance tester,Power Quality Analyzer and so on.
Close to Tianjin port, the transportation is convenient. our customers come from More than 50 countries, like America, England, Bulgaria, Brazil, Chile, Malysia, Vietnam and so on.
What's more, gurantee 1 year,life long maintance .Products through the CE, ISO, IEC certification, quality and reliable, factory price.
Warmly welcome all partners to join us for mutual benefits cooperation.
