0-80Kv Oportable transformer oil testing machine Six cup portable insulating oil dielectric strength test apparatus
Single/three/six oil cup structure avaliable for your choice
1,Applies to GB/T507-2002, DL/T429.9-1991 standards
2,Test voltage:0 to 80KV(optional)
3,Voltage distortion rate: <3%
4,Boost speed: 2 to 3.5KV/S (adjustable)
5,Static discharge time: 15 minutes (adjustable)
6,Boost interval: 5 minutes (adjustable)
7,Boost number: 1 to 6 times (adjustable)
8,Power supply: AC220V ±10% 50Hz ±1 Hz
9,Power: 200W
10,Suitable temperature: 0 to 45 degree celsius
11,Suitable humidity: <85%RH
Brief introduction:
In the power system minding and enterprise, there are a large number of electrical equipment, while internal
insulation is mostly oil filled insulation type, the insulating oil dielectric strength test is the conventional test
project that will be.
Features & Advantages:
1. Three or single oil cup structure, controlled by computer, can automatically done boost, keep,
step-down, stirring, static put, display calculation, printing, and so on a series of operation, suitable from
0-80 kV within the insulating oil pressure test.
2. The big screen dot matrix LCD monitor, test process through the Chinese/English menu hint, convenient test personnel operating.
3. With strong anti-jamming ability, can work as normal under strong electromagnetic field environment.
4. With pressure, flow, automatic back to zero and grounded protection device, ensure the safety of the
instrument itself and the operators.
5. Speed boost and stewing, interval time according to different experiment standard options
6. The instrument is also compatible with National Standard 2002 edition and 1986 edition, it's available that
according to the requirements from the definition test conditions.
From the date of purchase within one year instrument, is a product quality problem free repair replacement, lifetime supply of maintenance and technical services. The instrument has found anomalies or malfunctions please contact us to arrange the most convenient treatment options.
HuaZheng Electric Manufacturing (Baoding) Co.,Ltd is founded in 2008,the supplier of the State Grid in China.It means we are the supplier of the Chinese Government.And our products spread throughout the whole China.
Our main products : Insulation Oil Tester, Cable Fault Locator, High Voltage Generator,transformer tester, relay protection tester,insulation resistance tester,Power Quality Analyzer and so on.
Close to Tianjin port, the transportation is convenient. our customers come from More than 50 countries, like America, England, Bulgaria, Brazil, Chile, Malysia, Vietnam and so on.
What's more, gurantee 1 year,life long maintance .Products through the CE, ISO, IEC certification, quality and reliable, factory price.
Warmly welcome all partners to join us for mutual benefits cooperation.
