Help CenterPleated Polypropylene Filter TFOB-40-20FRF OILBLOCK ABSORPTION CARTRIDGE for TWINFILTER PARKER
Related Products
-
10,20,30,40 Inch Absorbent Cotton String Wound Filter Cartridge for Filtering Palm OilUS$ 0.3 - 20MOQ: 1 Piece -
Pleated Synthetic Filter Elements for Industrial Water, Solvents, Acids, D.I. , Alcohols PS-209-S1C-10-EBUS$ 8 - 20MOQ: 3 Pieces
-
UF Tubular Inorganic Ultrafiltration Porous Ceramic Membrane Filter Tube for Waste Water TreatmentUS$ 180 - 800MOQ: 5 Pieces
-
1 Micron Replace PECO AMMIN Filter Element JPMK-336-1A With Spring Pleated PolypropyleneUS$ 5 - 30MOQ: 1 Piece
-
0.2 Micron Ceramic Honeycomb Catalyst/Industrial Cordierite Honeycomb Ceramic Filter With 19 HolesUS$ 350 - 350MOQ: 30 Pieces
This cartridges are specifcally manufactured for the high effciency removal of free dispersed oils from water. Typical applications include bilge water treatment, contaminated surface run-off water and many other similar industrial process applications.
The cartridges employ a proprietary modifed polymer that both absorbs and chemically binds the hydrocarbon molecules into its interior matrices, the oil cannot be released once absorbed.
Consequently these properties make Oilblock cartridges an effective absorbent for free emulsifed and dissolved oils, synthetic lubricants, grease and a multitude of organic solvents
Features&Benefits
99% removal of oils in a single pass.
Cartridge blocks after saturation and no hydrocarbon bypass is possible.
The absorption capacity can be up to 4 times its own weight.
No direct contact with saturated
media during handling.
High flow rates.
Specially designed for the offshore industry.
Reliable and simple solution.
•Easy handling and operation.
Fit into existing cartridge flter units.
Manufacturing process eliminates voids in media and thus bypass issues.
Detailed technical data
Materials Of Construction |
Filter Media: |
Pleated Glass Microfiber(GF) ,Pleated Polypropylene |
|
Support Layers: |
Polypropylene |
||
Micron Rating: |
0.45, 1.0, 3.0, 5.0, 10um |
||
Inner Core: |
Polypropylene |
||
Outer Cage, End caps: |
Polypropylene |
||
Seal Method: |
Thermal Bonded, No Adhesives |
||
O-rings/gaskets: |
Silicone, Nitrile, EPDM, Viton, Teflon |
||
Filtration Efficiency |
≥90% |
||
Cartridge Dimensions |
Outer Diameter |
2.5'' |
|
Inner Diameter |
25.4mm(1.1''),33mm(1.30'') |
||
Length(based on DOE end caps) |
10, 20, 30, 40 |
||
Filtration Area(m2) |
0.5 m2 per 10'' |
||
Operating Conditions |
Operating Conditions |
Normal Operating Temperature: |
|
Max.Operating Temperature: |
120℃ at P≤2.5 bar (14.5 psi) |
||
Max. Differential Pressure |
|||
Normal Flow Direction: |
4.2 bar (60.9 psi) at 25℃ (77℉) |
||
Reverse Flow Direction: |
2.1 bar (30.5 psi) at 25℃ (77℉). |
||
PH Value Compatibility: |
1-13 |
||
End cap model |
(1) DOE double open ends ,sealing washer; (2)DOE open ends, (3)222 sealing ring single open end ,with fin, (4)222 sealing ring ,single open end with fin, (5)226 sealing ring single open end,fin tail (6)226 sealing ring,single open end with fin. |
||
Produced water
Displacement clean up
Acid flow back
Completion fluids
Pipeline, system purge & hydro
test discharges
Run-off water
