CTB 010 / CR11 AC220V / Standard on/off version / DN100 4'' electric actuator SS304 butterfly valve
For other speicificaitons, please consult the sales representative
Elegant shape, excellent performance, diamond quality, and long service life.
1. Flexible control: intelligent control and manual control; passive and active output.
2.Portable Size: its weight and volume are about thirty percent of the same kind products.
3.Stable Performance: smart aluminum alloy pressure casting housing reduces electromagnetic disturbance.
4.Wear-resistant: forged with special copper alloy, it features high strength and super wear-resistance.
5.Safety Guarantee: passing of AC1500v pressure-withstand test and F grade of insulated electric machine guarantees the operation safety.
6.Simple Connection: single-phase power simplifies wire connection. AC 380V power supply is also available.
7.Protection mechanisms: double position limits, over-heat protection, overload protection (optional).
8.Multiple speeds : open/close time can be 9s,13s,15s,30s,100s(set in the the factory).
9.Anti-rust and anti-corrosion: the one piece machine support, all the couplings and screws are made of stainless steel.
10.Intelligent numerical control: with the integrated intelligent control module, the actuator can realize accurate numerical regulation (by changing input signal between 4-20mA), and other functions like self-diagnosis.
11.High precision control: the worm-wheel output axle integration design avoids the gap between key connections, helps to achieve higher transmission precision.
12.Simple maintenance: no need of adding oil, and have good waterproof and anti-rust properties; could be installed at any angle.
Pure water and raw water pipeline systems; drainage and sewage systems; industrial wastewater treatment; salt water and sea water pipeline systems; acid-base and chemical solution systems etc .
| CTB | CTB005 | CTB010 | CTB016 | CTB025 | CTB050 | CTB100 | CTB200 |
| Voltage | AC380 AC220 DC24V DC12V | ||||||
| Torque | 20NM | 100NM | 160NM | 250NM | 500NM | 1000NM | 2000NM |
| Opening Time | 20S | 30,60S | 100S | ||||
| Power | 15W | 23W | 23W | 50W | 90W | 100W | 100W |
| Protection | Overheat protection (automatic restorer) | ||||||
| Input Signal | 4-20mA or 0-10V for option | ||||||
| Output Signal | 4-20mA or 0-10V for option | ||||||
| Turning Angle | 0-360° | 0-90° | |||||
| Environmental temperature | -25°~ 60° | ||||||
| Pressure-withstanding value | 1500VAC/Min | ||||||
| Weight | 2.5KG | 3.7KG | 3.7KG | 6.8KG | 8.0KG | 12KG | 12KG |
| Mounting Angle | Any Angle | ||||||
| Waterproof | IP65 | ||||||
| Cabinet Material | Aluminium alloy die-castings | ||||||
| Manual Operation | With manual override | ||||||
| Limit Switch | Electric operation,fullly open/closed limit switch,manual operation,mechanical block | ||||||
Located in Tianjin, China, Tianjin Tianfei High-Tech valve company have been specializing in electric ball valve and butterfly valve industry for 12 years. Equipped with a professional R & D team, we have won a number of technology patents. Our products have adopted ISO9000:2000, CE, ROHS, NSF61 certifications. With reliable quality and competitive prices, they have earned a good reputation among the customers from all over the world.
Our motto is Innovation, Simplification, Efficiency. Our mission is to meet customers’ needs with quality products and professional service. We look forward to building a sustainable and mutually beneficial cooperative relationship with you!
FAQ
1. Are you a manufacturer or a trading company?
We are a manufacturer, and we have been in the electric valve field for more than 12 years. So we have advantage in price. We also could do OEM.
2. What's the payment method?
T/T, Paypal, Western Union, Moneygram, Aliexpress, L/C etc.
3.What's your Minimum Order Quantity (MOQ)?
Our MOQ is 1 piece.
4. What about the delivery time?
Samples would take about 3 working days, and for large orders, the delivery time depends on the quantity of the order.
5.Would you provide a discount if l have a large order?
Yes, we could offer different discounts according to your order quantity.
6.Where is the factory located?
Tianjin city, and welcome to visit our factory.
