Slocable IP68 50A Terminal Connector Pin for Junction Box Connector in Solar System
- shenzhen
- T/T Credit Card
You May Like
-
Slocable TUV CE Approved 50A 40A 30A CN40 Connector IP68 IP67 for Solar Cable
-
Slocable High Quality CN40 Waterproof DC Solar Connectors Made in China
-
Slocable Solar IP68 Waterproof 2.5mm2 10mm2 6mm2 4mm2 Plug Socket 1500V PV Connector
-
SLOCABLE Waterproof With High Current Solar System 2 in 1out PV Y-branch Connector
-
Hot Sell Slocbale TUV Waterproof DC PV Connector Solar Connector CN40-CM Plug and Socket
-
Slocable Solar Panel Connector 2 Combining to 1 T Y Branch Connector
Product Details
| Brand Name | Slocable | Place of Origin | Guangdong, China | |
| Model Number | CN40-CM | Type | MMCX | |
Product Description
Slocable IP68 Solar and Terminal Connector Pin for Junction Box Connector in Solar System
Technical Data of Junction Box Connector
Rated Current | 30A (2.5-6mm2), 50A (10mm2) |
Rated Voltage | 1500V/1000V DC |
Test Voltage | 6000V (50Hz,1min) |
Overvoltage Category | Category III |
Pollution Degree | 2 |
Contact Resistance | <0.5mΩ |
Degree of Protection | IP68 |
Flame Class | UL94-V0 |
Safety Class | II |
Insertion Force / Withdrawal Force | ≤50N / ≥50N |
Connecting System | Crimp connection |
Temperature Range | -40~+85°C |
Contact Material | Copper, Tin Plated |
Insulation Material | PPO |
Suitable Cable | OD4.5-8.5mm (2.5-10mm²) |
Pictures of Junction Box Connector
Click the following picture to get more Slocable products:
Q1: What is your company's Main Products ? You are the Manufacturer or the trader ?
Solar Cables, Solar Connectors, PV Fuse Holder, Circuit breakers and other solar relative products. We're the Manufacturer with more than 12 years experience.
1) All raw materials we selected are the highest quality.
2) Professional and skilful workers care every details in handling the producing.
3) Quality Control Department is specially responsible for quality checking in each process.
Q4: Do you provide OEM Project Service?
OEM & ODM order is warmly welcome and we have fully successful experience in OEM projects.
What's more, our R&D team will give you the professional suggestions.
Q5: How could I get the Sample?
We are honored to offer you samples, whihc is free, but you will need to pay the international courier freight.
If you have a courier account or forwarder in China, you can send your courier to collect samples.
Q6: How long is the Delivery Time?
1) For Sample: 1-3 Days ;
2) For small orders: 3-10 Days;
3) For mass orders: 10-18 Days.
It is better to communicate with us if you are interested to place an order.
