Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > Home Application Electric Blankets Heating Wire Mat Wood Floor Heaating Mat

Home Application Electric Blankets Heating Wire Mat Wood Floor Heaating Mat

Home Application Electric Blankets Heating Wire Mat Wood Floor Heaating Mat photo-1
Home Application Electric Blankets Heating Wire Mat Wood Floor Heaating Mat photo-2
Home Application Electric Blankets Heating Wire Mat Wood Floor Heaating Mat photo-3
Home Application Electric Blankets Heating Wire Mat Wood Floor Heaating Mat photo-4
Home Application Electric Blankets Heating Wire Mat Wood Floor Heaating Mat photo-5
Home Application Electric Blankets Heating Wire Mat Wood Floor Heaating Mat photo-6
US$ 7 - 7 MOQ: 50 Square Meters
Key Specifications
Get Latest Price
Brand Name:
Youyu
Place of Origin:
Anhui, China
Model Number:
customized
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port in China
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Youyu
Place of Origin Anhui, China
Model Number customized
Application Indoor underfloor heating

Home Application Electric Blankets Heating Wire Mat wood floor heaating mat

Product Description

Home Application Electric Blankets Heating Wire Mat wood floor heaating mat

Voltage220V
Power150w/m2
Heating ConductorAlloy Wire
InsulationFEP
ShieldAluminum foil + Copper wire
Outer SheathPVC
Max. Surface Temperature70℃
Max. Withstand Temperature120℃


Home Application Electric Blankets Heating Wire Mat wood floor heaating mat

Indoor Underfloor Heating Mat

Heating mat is a good heating system. It is easy to install for a variety of floor coverings, whether concrete, wood or old tile or terrazzo. It is installed with tile adhesive and has almost no effect on the ground elevation. Heating mat can also be laid directly on the original ground without the need for other treatment of the original ground. In addition, the thin, pre-heated layer gives you the desired floor temperature in 20-30 minutes after starting the system, so this fast heating system is the best choice for home. Heating mat used for overall heating, comfortable heating, wall heating, Indoor high-level demanding and the second decoration. Heating mat are divided into single-conductor bathroom floor electric warm feet mat and twin conductor bathroom floor electric warm feet mat.

Home Application Electric Blankets Heating Wire Mat wood floor heaating mat



Structure

Single conductor heating mat

Twin conductor heating mat

Glass net

10*10mm

300 g/square meter Back double-sided tape

10*10mm

300 g/square meter Back double-sided tape

Thickness

4-4.5mm

3-5.5mm

Power output

100w/square meter,150 w/square meter

150 w/square meter

Rated voltage

220v(Customized)

220v(Customized )

Length

2*2m

1*2m

Cable construction

single conductor

twin conductor

Outside diameter

2.5mm

3mm

Insulation

Teflon(150℃ CFEP)

Teflon(150℃ CFEP)

Conductor

Teflon(150℃ CFEP)

Teflon(150℃ CFEP)

Shield

Aluminum foil + copper wire

Aluminum foil + copper wire

Max. Ambient Temp

120 ℃

120

Company Information

Home Application Electric Blankets Heating Wire Mat wood floor heaating mat

Client & Certificate

Home Application Electric Blankets Heating Wire Mat wood floor heaating matHome Application Electric Blankets Heating Wire Mat wood floor heaating mat

FAQ
1. How much electricity is consumed per hour?
Consider an average room size of 100m2 . The heated area is approximately 80%, or 80m2 .
In the case of the 150W mats, when the heater is ON, the hourly consumption is 1500W times 80m2.
When the recommended thermostat is turned on, take 100m2 as an example. The room is filled with heat about 20min~30min, which is between 450W and 750W. Of course, the specific cost depends on your electricity consumption and electricity unit price.

2. Do I use insulation materials?
We recommend that you use insulation materials. On the one hand, it is for your safety considerations, on the other hand, because it can lock the heat, the preheating will be faster, and the power consumption will be reduced.

3. Is it safe to use in a humid place?
Yes, our products are of high quality and have a grounding wire.

4.  How long is the warranty time?
25 years for heating cable & heating mat.
2 years for for constant wattage/self-regulating heating cable and thermostats.

5. Can I crop it?
Yes, you can crop the grid

6. What is the thickness of the cable?
The cable is 3.5mm thick.
