Hot Dip Galvanized 15mm Imc Pipe Price List

FOB Price

US$ 1 - 100 / Piece

2000 Pieces(Min. Order)

Port qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin

Shandong, China

Product Description

1.Standard:UL1242 & ANSI C80.6 imc conduit

2.Tade Size : from 1/2” to 4”

3.Length: 3050mm or according to customer’s requirement

4.Both ends: threaded both ends with one coupling and plastic cap

5.Usage: through the electrical wires with the purpose of protection for the electrical raceway system
6.Surface finished: Hot dip galvanized(HDG).
7.Material : carbon steel coil

8.Package: the conduits coverd with pvc paper then tied with steel straps

9.Delivery time: 20 to 30 days after we receive your advance payment or copy of L/C

10.Payment Term: L/C at sight or T/T

Dimension and Weight Chart

Trade Size		Nominal Wt. per 100Ft(30.5M)		Nominal Outside Diameter		Nominal Wall Thickness
U.S.	Metric	Lbs	Kg	In.	mm	In.	mm
1/2	16	62	28.1	0.815	20.70	0.070	1.79
3/4	21	84	38.1	1.029	26.13	0.075	1.90
1	27	119	54.0	1.290	32.76	0.085	2.16
1-1/4	35	158	71.7	1.638	41.60	0.085	2.16
1-1/2	41	194	88.0	1.883	47.82	0.090	2.29
2	53	256	116.1	2.360	59.94	0.095	2.41
2-1/2	63	441	200.0	2.857	72.56	0.140	3.56
3	78	543	246.3	3.476	88.29	0.140	3.56
3-1/2	91	629	285.3	3.971	100.86	0.140	3.56
4	103	700	317.5	4.466	113.43	0.140	3.56

Applicable tolerances:

Length: 10Ft (3.05m) ± ¼” (±6.35mm).

Outside Diameter: ½”-1” ±0.005” (±0.13mm); 1¼-”-2” ±0.0075” (±0.19mm);2½”-4” ±0.10” (±0.25mm);

Wall thickness tolerances: ½-”-2” ±0.15” (±0.38mm);2½”-4” ±0.20” (±0.51mm)
