Hot Dip Galvanized Electrical 1 Rigid Conduit 90 Degree Elbow List

  Rigid steel conduit elbow is manufactured from prime conduit shell with high-strength in accordance with the latest specifications and standard of ANSI C80.1(UL6).

  The interior and exterior surfaces of elbows are free from defect with a smooth welded seam, and are thoroughly and evenly coated with zinc using hot dip galvanizing process, so that metal-to-metal contact and galvanic protection against corrosion are provided, and the surface of elbows adopt the clear post-galvanizing coating to provide further protection against corrosion.

  Elbows are produced in normal trade sizes from 1/2" to 6", the degrees including 90deg, 60 deg, 45 deg, 30 deg, 22.5deg, 15deg or according to customer's request.

  Elbows are threaded on both ends, a thread protector with industry color-coded by sizes from 3" to 6" applied.

  The elbows are used to connect the rigid steel conduit to change the way of the conduit.

Detailed Product Description

• Standard: UL6 & ANSI C80.1
• Certificates: UL Listed, certificate No.E308290 (177709-001)
• Trade Size: From 1/2” to 6”

                              90 deg/ 45 deg/ 30 deg/ 22.5 deg /15deg

• Both ends:Threaded (NPT) both ends with plastic caps
• Usage:For rigid conduit(RMC) connection
• Surface Finished: Hot dip galvanized(HDG).
• Material: Carbon steel coil
• Package:  Carton
• Delivery Time: 20 to 30 days after we receive your advance payment or copy of L/C
• Payment Term: L/C at sight or T/T

Dimension and Weight Chart (90DEG ELBOW)
