RIGID CONDUIT ELBOWS / BENDS
Rigid steel conduit elbow is manufactured from prime conduit shell with high-strength in accordance with the latest specifications and standard of ANSI C80.1(UL6).
The interior and exterior surfaces of elbows are free from defect with a smooth welded seam, and are thoroughly and evenly coated with zinc using hot dip galvanizing process, so that metal-to-metal contact and galvanic protection against corrosion are provided, and the surface of elbows adopt the clear post-galvanizing coating to provide further protection against corrosion.
Elbows are produced in normal trade sizes from 1/2" to 6", the degrees including 90deg, 60 deg, 45 deg, 30 deg, 22.5deg, 15deg or according to customer's request.
Elbows are threaded on both ends, a thread protector with industry color-coded by sizes from 3" to 6" applied.
The elbows are used to connect the rigid steel conduit to change the way of the conduit.
Detailed Product Description
- Standard: UL6 & ANSI C80.1
- Certificates: UL Listed, certificate No.E308290 (177709-001)
- Trade Size: From 1/2” to 6”
90 deg/ 45 deg/ 30 deg/ 22.5 deg /15deg
- Both ends:Threaded (NPT) both ends with plastic caps
- Usage:For rigid conduit(RMC) connection
- Surface Finished: Hot dip galvanized(HDG).
- Material: Carbon steel coil
- Package: Carton
- Delivery Time: 20 to 30 days after we receive your advance payment or copy of L/C
- Payment Term: L/C at sight or T/T
Dimension and Weight Chart (90DEG ELBOW)
| SIZE | Mini.UL Radius "A" | Weight per 100PCS | PCS/ Carton | Weight/ Carton | |||
| mm | in. | KG | LBS | KG | LBS | ||
| 1/2" | 102 | 4.016 | 29.9 | 66 | 50 | 14.94 | 33 |
| 3/4" | 114 | 4.488 | 47.0 | 104 | 50 | 23.49 | 52 |
| 1" | 146 | 5.748 | 83.8 | 185 | 20 | 16.75 | 37 |
| 1-1/4" | 184 | 7.244 | 139.4 | 307 | 20 | 27.89 | 61 |
| 1-1/2" | 210 | 8.268 | 191.2 | 421 | 10 | 19.12 | 42 |
| 2" | 241 | 9.488 | 291.9 | 644 | 10 | 29.19 | 64 |
| 2-1/2" | 267 | 10.512 | 549.6 | 1212 | 50 | 274.82 | 606 |
| 3" | 330 | 12.992 | 854.8 | 1884 | 35 | 299.16 | 660 |
| 3-1/2" | 381 | 15.000 | 1190.5 | 2624 | 35 | 416.66 | 919 |
| 4" | 406 | 15.984 | 1485.2 | 3274 | 25 | 371.30 | 819 |
| 5" | 610 | 24.016 | 3173.8 | 6997 | BULK | ||
| 6" | 762 | 30.000 | 5119.5 | 11286 | BULK | ||
REMARK: Elbows special threading or special radius available upon request.
