Electrical Metallic Tubing (EMT)

Product Introduction

EMT is manufactured from high-strength steel coil, and produced according to the standard of ANSI C80.3(UL797). The interior surface of our conduit is free from defect with a smooth welded seam. It is hot dipped galvanized inside and outside, so that metal-to-metal contact and galvanic protection against corrosion are provided, and the surface of the conduit is coated with a clear lacquer coating to inhibit white rust and increase corrosion resistance. The interior surface provides a smooth continuous raceway for easy wire pulling.  Our EMT conduit has excellent ductility, providing for uniform bending and cutting.

• Length: 3050mm or according to customer’s requirement
• Usage: Through the electrical wires with the purpose of protection for the electrical raceway system
• Surface finished: Hot Dip Galvanized(HDG).

• Material : Carbon Steel Coil
• Package: The conduits coverd with pvc paper then tied with steel straps
• Delivery time: 20 to 30 days after we receive your advance payment or copy of L/C
• Payment Term: L/C at sight or T/T

• UL Certificate No. : E340594(177709-001)

Dimension and Weight Chart

Applicable Tolerances:

Length: 10Ft (3.05m) ± ¼” (±6 mm).

Outside Diameter: ½”-2” ±0.005” (±0.13mm); 2½” ±0.010” (±0.25mm); 3” ±0.015” (±0.38mm); 3½”-4” ±0.020” (±0.51mm)

Specifications:

 East Conduit EMT pipe is manufactured in accordance with the latest edition of the following:

•  American National Standard for Rigid Steel EMT (ANSI® C80.3)
•  Underwriters Laboratories Standard for EMT-Steel (UL797)
•  National Electric Code® 2002 Article 358 (1999 NEC® Article 348)
