Hot Dip Galvanized Conduit Pipes 3 4 Emt Conduit Fill
- QINGDAO TIANJIN SHANGHAI
- T/T Credit Card
You May Like
-
Hot Dip Galvanized Calibres de Tuberia Emt for Wire Pulling
-
Hot Dip Galvanized Emt Conduits and Fittings Elbow With Consistent Quality
-
Hot Dip Galvanized Emt Price List With Consistent Quality
-
Hot Dip Galvanized Conduit Pipes Emt Pipe Dimensions
-
Hot Dip Galvanized Tuberia Conduit Emt 25 mm Especificaciones Tecnicas
-
Hot Dip Galvanized Emt Conduit Price With Consistent Quality
Product Details
| Place of Origin | Shandong, China | Certification | UL | |
| Thickness | 1.07, 2.11 | |||
| Technique | ERW | |||
| Alloy Or Not | Non-alloy | |||
| Outer Diameter | 17.93 - 114.3 mm | Secondary Or Not | Non-secondary | |
| Special Pipe | EMT Pipe | Section Shape | Round |
Product Description
Electrical Metallic Tubing (EMT)
Product Introduction
EMT is manufactured from high-strength steel coil, and produced according to the standard of ANSI C80.3(UL797). The interior surface of our conduit is free from defect with a smooth welded seam. It is hot dipped galvanized inside and outside, so that metal-to-metal contact and galvanic protection against corrosion are provided, and the surface of the conduit is coated with a clear lacquer coating to inhibit white rust and increase corrosion resistance. The interior surface provides a smooth continuous raceway for easy wire pulling. Our EMT conduit has excellent ductility, providing for uniform bending and cutting.
- Length: 3050mm or according to customer’s requirement
- Usage: Through the electrical wires with the purpose of protection for the electrical raceway system
- Surface finished: Hot Dip Galvanized(HDG).
- Material : Carbon Steel Coil
- Package: The conduits coverd with pvc paper then tied with steel straps
- Delivery time: 20 to 30 days after we receive your advance payment or copy of L/C
- Payment Term: L/C at sight or T/T
-
UL Certificate No. : E340594(177709-001)
Dimension and Weight Chart
|
Nominal Wall Thickness |
|||||||
|
U.S. |
Metric |
Lbs |
Kg |
In. |
mm |
In. |
mm |
|
16 |
30 |
13.5 |
0.706 |
17.93 |
0.042 |
1.07 |
|
|
3/4 |
21 |
46 |
20.7 |
0.922 |
23.42 |
0.049 |
1.24 |
|
1 |
27 |
67 |
30.6 |
1.163 |
29.54 |
0.057 |
1.45 |
|
1-1/4 |
35 |
101 |
45.6 |
1.510 |
38.35 |
0.065 |
1.65 |
|
1-1/2 |
41 |
116 |
52.8 |
1.740 |
44.20 |
0.065 |
1.65 |
|
2 |
53 |
148 |
67.2 |
2.197 |
55.80 |
0.065 |
1.65 |
|
2-1/2 |
63 |
216 |
97.9 |
2.875 |
73.03 |
0.072 |
1.83 |
|
3 |
78 |
263 |
119.3 |
3.500 |
88.90 |
0.072 |
1.83 |
|
3-1/2 |
91 |
349 |
158.3 |
4.000 |
101.60 |
0.083 |
2.11 |
|
4 |
103 |
393 |
178.3 |
4.500 |
114.30 |
0.083 |
2.11 |
Applicable Tolerances:
Length: 10Ft (3.05m) ± ¼” (±6 mm).
Outside Diameter: ½”-2” ±0.005” (±0.13mm); 2½” ±0.010” (±0.25mm); 3” ±0.015” (±0.38mm); 3½”-4” ±0.020” (±0.51mm)
Specifications:
East Conduit EMT pipe is manufactured in accordance with the latest edition of the following:
- American National Standard for Rigid Steel EMT (ANSI® C80.3)
- Underwriters Laboratories Standard for EMT-Steel (UL797)
- National Electric Code® 2002 Article 358 (1999 NEC® Article 348)
