UNS N05500 Nickel Alloy Monel K500 Forged Steel Round Bar
US$ 26.5 - 26.5
MOQ: 500 Kilograms
Key Specifications
Get Latest Price
Brand Name:
kcgy
Place of Origin:
China
Model Number:
monel500,monel 400
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin/qingdao/shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Inconel 686 EN 2.4606 Threaded Rod Screw GasketUS$ 20 - 30MOQ: 500 Kilograms -
Best Quality Invar 36 W.Nr.1.3912 Ni36 Carbon Steel Coil PriceUS$ 20 - 40MOQ: 500 Kilograms
-
Nicrofer 3127 HMo DIN 1.4562 Nickel Plate Price kgUS$ 20 - 40MOQ: 500 Kilograms
-
Stainless Steel A276 Hastelloy B3 Nickel Alloy Steel Wire RodUS$ 21 - 58MOQ: 500 Kilograms
-
Mirror Finish AISI Stainless Steel Sheet 304 JIS Grade SUS304 PlateUS$ 1,500 - 2,500MOQ: 5 Tons
Brand Name
kcgy
Place of Origin
China
Model Number
monel500,monel 400
Certification
ISO
Shape
Round
Type
Round
Standard
JIS, AISI, ASTM, GB, DIN, EN
Special Use
Valve Steels
UNS N05500 Nickel alloy Monel K500 Forged steel round bar
Product Description
Monel K500 UNS N05500 Nickel alloy not only has excellent mechanical properties
such as high strength, corrosion resistance and non-magnetism, but also has the
same corrosion resistance as monel 400. It can be used as pump shaft material,
suitable for working under bad geological mining conditions with high sulfur and high
wax layer. Since the alloy has no plastic-brittle transition temperature, it is suitable for
all kinds of cryogenic equipment. This alloy is mainly used for pump shaft and valve stem,
conveyor scraper, oil well drilling ring, elastic parts, valve pad, etc. Suitable for petroleum,
chemical shipbuilding, pharmaceutical, electronic sectors.
1--Production Standard:ASTM B865 ,AMS 4676
2--Chemical
| Element | (%) |
| NI | 63.0min |
| CU | 27min~33max |
| FE | 2.0max |
| MN | 1.5max |
| C | 0.25max |
| SI | 0.5max |
| AL | 2.3min~3.15max |
| TI | 0.35min~0.85max |
| S | 0.01max |
3---Physical Performance
Density |
0.318 lb / in3 |
8.80g/cm3 |
|
Elasticity modulus |
26 000 ksi |
Resistivity |
5.11e-005 ohm-cm |
Heating |
0.427 J/g-°C |
Thermal conductivity |
22 W/m-°C |
Melting point |
1300 - 1350 °C |
Magnetic |
200H(At 70 F) |
thermal expansivity in./in./ F x 106 |
|
70-200F |
7.7 |
70 - 400 F |
8.6 |
70 - 800 F |
8.9 |
70 - 1000 F |
9.1 |
Tensile(Mpa) |
Yield(Mpa)
(0.2% Offset)
ksi
|
Elongation
%
|
Hardness
Brinell
(3000-kg)
|
Rockwell
B
|
||
70-90 |
482-621 |
25-60 |
172-413 |
45-30 |
110-170 |
60-86 |
Packaging & Shipping
Nickel Alloy Monel 500 steel bar can be cut to short length as required.
If the length is less than 500mm,the bars will be packed in woodencase.
If the length is more than 500mm,the bars can be packed by strong steel strip.
20FT container can hold max 27tons, with length max 5.8mtr
40FT container can hold max 27tons, with length max 11.8mtr.
Our Services
IN ADDITION TO NICKEL ALLOY MONEL K500 STEEL BAR,WE ALSO CAN OFFER:
- STAINLESS STEEL PIPE(SEAMLESS&WELDED)
- CARBON STEEL PIPE(SEAMLESS&WELDED)
- SQUARE RECTANGULAR TUBE
- STAINLESS STEEL BAR
- ANGLE&CHANNEL&BEAMS
- SPEICAL SHAPE SECTION
