Help CenterDrawn Over Mandrel 4140 DOM Honed and Hydraulic Tubing
Related Products
-
Drawn Over Mandrel (DOM) Aisi 4130 Alloy Steel Pipe Ready for HonedUS$ 1,500 - 2,100MOQ: 5 Tons -
DIN2391 Pneumatic / Hydraulic Cylinder Honed Tubes for Dump HoistUS$ 800 - 2,260MOQ: 25 Tons
-
Cold Drawn Seamless Q345B Honed Tube For Hoist CylinderUS$ 860 - 1,230MOQ: 25 Tons
-
Cold Drawn DIN 2391 Hydraulic Cylinder Tube ST52 Heavy Wall Mechanical TubingUS$ 680 - 1,050MOQ: 25 Tons
-
DIN 2391 Seamless Steel Honed Precision Mechanical TubeUS$ 680 - 1,050MOQ: 25 Tons
ASTM A519 | |
Seamless carbon and Alloy Steel Mechanical Tubing | |
Application |
For mechanical engineering. |
Grade and Chemical Composition (%)
Grade |
C |
Mn |
P≤ |
S≤ |
Si |
Cr |
Mo |
1020 |
0.18-0.23 |
0.30-0.60 |
0.040 |
0.050 |
- |
- |
- |
1026 |
0.22-0.28 |
0.60-0.90 |
0.040 |
0.050 |
- |
- |
- |
4130 |
0.28-0.33 |
0.40-0.60 |
0.040 |
0.040 |
0.15-0.35 |
0.80-1.10 |
0.15-0.25 |
4140 |
0.38-0.43 |
0.75-1.00 |
0.040 |
0.040 |
0.15-0.35 |
0.80-1.10 |
0.15-0.35 |
Mechanical Properties:
|
|
MPa |
|
|
1020 |
CW |
≥414 |
≥483 |
≥5% |
|
SR |
≥345 |
≥448 |
≥10% |
|
A |
≥193 |
≥331 |
≥30% |
|
N |
≥234 |
≥379 |
≥22% |
1025 |
CW |
≥448 |
≥517 |
≥5% |
|
SR |
≥379 |
≥483 |
≥8% |
|
A |
≥207 |
≥365 |
≥25% |
|
N |
≥248 |
≥379 |
≥22% |
4130 |
SR |
≥586 |
≥724 |
≥10% |
|
A |
≥379 |
≥517 |
≥30% |
|
N |
≥414 |
≥621 |
≥20% |
4140 |
SR |
≥689 |
≥855 |
≥10% |
|
A |
≥414 |
≥552 |
≥25% |
|
N |
≥621 |
≥855 |
≥20% |
Honed Tubing: Hydraulic cylinder tubing is produced using our “Suitable To Hone” Drawn Over Mandrel (DOM) and Cold Drawn Seamless (CDS). The honing process involves using abrasive polishing stones and abrasive paper to remove small amounts of material, to produce extremely precise ID dimensions and improved finishes. Honed tubing is ready to use for hydraulic cylinder applications without further ID processing.
· Made from grades 1020/1026 and ST52.3 ,4130,4140
· Size Range: 1.0” ID – 14.0” Honed ID; 1/8” – 1” wall thickness
· Stocked in 17’ - 24’ random lengths
· Cut to length service available
· Standard and metric sizes
· Suitable to hone sizes
· 14 Max Ra ID Finish
Cold Drawn Seamless (CDS) 4140 alloy pipe ready for honed
Surface Roughness: |
Ra - 0.2 ~ 0.4μm |
Tolerance on Wall Thickness: |
< Ø120 mm +/- 5% of wall thickness |
OD Tolerance |
< Ø 40 mm +/- 0.2 mm |
Straightness: |
< 1 mm/mtr |
Packing: |
Inside surface protected with rust preventive oil, both ends sealed with plastic caps and packed in bundles tied with strips. |
Certificate: |
Material certificates as per EN 10204/3.1 |
AISI 4140 alloy steel honed pipe
Cold drawn 4140 steel honed pipe (packing and stock)
