---- Product Characteristics----
• More Power:
1. Supporting Lovol power 130 horsepower engine, low fuel consumption, large torque reserves, strong power;
2. Optional Yuchai turbocharged engine, increase the matching dynamic diversity, to meet different user needs;
3. Power emissions upgrades, performance upgrades, low fuel consumption, high reliability.
• More advanced technology:
1. The gearbox adopts the synchronizer shuttle shift, the full helical gear transmission, the manipulation is more flexible and light;
2. Front drive with universal joint drive shaft, transmission torque, high reliability;
Hydraulic system independent oil supply, high reliability;
• More efficient jobs:
1. 16 +16 shuttle shift gearbox, stall speed matching is reasonable, high efficiency;
2. Using 320L large fuel tank reserves, continuous operation for a long time;
3. Ⅱ type three-point hanging articulated device for a variety of farm machinery operations, high operating efficiency;
• Driving is more comfortable
The whole machine has superior performance, advanced structure, stylish and streamlined design, fully enclosed cab, optional air conditioning, heating system, sound and so on, luxurious and comfortable;
Optional electronic control lifter, comfortable and lightweight;
model | HW1304 |
Drive type | 4*4 |
Engine brand | YTO |
Engine model | LR6M5-23 |
Type | 6 cylinder,water-cooling, In-line, direct injection |
Capacity of fuel tank(L) | 41 |
Bore*Stroke | 110*135 |
Rated speed (r/min) | 2300 |
Engine power (hp) | 130hp/95.5kw |
Clutch | 13 inch dual clutch |
PTO size | 8 teeth φ38 |
PTO Speed(rpm) | 540/720 |
Gear shift | 16F+8R |
Hydraulic output valve | 3-Way optional |
Category of 3-point link | Category II |
Dimension(L*W*H) mm | 4780×2050×2720 |
Min.operation weight | 4155kg |
Wheel base(mm) | 2510 |
Track base(mm) front wheel | 1610 |
Track base(mm) rear wheel | 1610-1996Adjustable |
The Min. clearance(mm) | 470 |
Front tyre | 14.9-26 |
Rear tyre | 18.4-38 |
Steering type | Hydraulic Steering |
Trade and packing terms
MOQ | 1PC |
Package | Iron frame or wooden case |
Delivery terms | FOB,CNF,CIF,EXW |
Lead time | 7-15 working day in regularly,or subject to the order quantity. |
Payment Type | T/T,L/C, |
Supply Ablitity | 2000 Sets/Month |
shipping Port | Qingdao |
Company introduction
Business Type | Manufacture,Trading Company |
Location | Weifang City,Shandong Province.China |
Year Eatablished | 1984 |
Registration No. | 370702200001927 |
Company Certification | CE ISO9001 |
Main products | rotary tiller,trailer,potato planter, disc plough, disc harrow, rotary mower , walking tractors and so on. With good quality, excellent performance, our products annually export to countries around the world, and we have gained the majority of customers trust. |
Trade Assurance:
As a member of alibaba, we gain the support form Alibaba depends on the good quality and reputation, such as “Trade Assurance”
Trade Assurance is a free protection service for buyers.
The service is offered by participating suppliers, and is designed to protect your payment if your order is not shipped on time, or if the pre-shipment product quality (optional) does not match the terms agreed on your contract.
It will reassure your worries about delivery time and the quality.
