Home > Products > Acid-alkali Resistant Conveyor Belt > Acid-alkali Resistant Conveyor Belt conveyor belt wholesaler material handling conveyor belt
Acid-alkali Resistant Conveyor Belt conveyor belt wholesaler material handling conveyor belt
- 2000 Roll / Rolls per Month
- Tianjin
- T/T L/C
Product Details
Brand Name: | Baoxiang |
Product Description
Acid-alkali Resistant Conveyor Belt conveyor belt wholesaler material handling conveyor belt
Baoxiang Acid and alkali resistant conveyor belt is a kind of working environment suitable for contact with acid and alkali. It is blended with rubber and plastic and filled with inert materials with excellent acid and alkali resistance.
PRODUCT DESCRIPTION
Acid-alkali Resistant Properties of Rubber Cover, Conveyor Belt Wholesaler
Class | Soak liquid | Concentration | Soak conditions(℃×h) | Change rate of properties before and after soaking | |
Volume expansion rate | Change rate of tensile strength | ||||
A1 | Hydrochloric acid (HCl) | 18% | 50℃×96h | ≤+10% | ≥-10% |
A2 | Sulfuric acid(H2SO4) | 50% | 50℃×96h | ≤+10% | ≥-10% |
A3 | Sodium hydroxide(NaOH) | 48% | 50℃×96h | ≤+10% | ≥-10% |
Full-thickness tensile propertiesa.
a. Full thickness, longitudinal tensile strength after-aging test reduces not lower than 30% of before-aging values.
b. Full thickness, longitudinal elongation at reference force, not more than 4%.
c. Longitudinal tensile strength, not less than the below table. (N/mm)
Nominal belt type | 160 | 200 | 250 | 315 | 400 | 500 | 630 |
800 | 1000 | 1250 | 1600 | 2000 | 2500 | 3150 |
Ply adhesion at normal temperature
Item | Ply to ply | Rubber cover to ply |
All samples average value/ (N/mm) ≥ | 4.5 | 3.5 |
All samples min peak value/ (N/mm) ≥ | 3.9 | 2.9 |
Covered with rubber | Index name | Index | |
Hardness(shor A)degree | 55±5 | ||
Abrasion value/1.6cm,≤ | 1.20 | ||
Tensile strength Mpa≥ | 12.0 | ||
elongation at break %≤ | 400 | ||
Acid resistance coefficient:(15-25℃,24h40%H 2 SO 4 ) | ≥0.8 | ||
Through thickness | Adhesive strength of tape and cloth | Rubber cover>1.5mm | ≥3.2N/mm |
Interlaminar (longitudinal mean) bonding strength of adhesive tape | ≥3.2N/mm | ||
Elongation at break (total) | ≥10% |
Acid And Alkali Resistant Conveyor Belt Features: cotton canvas, nylon canvas or polyester canvas as the core, with good elasticity, good groove performance and low elongation. The coating adhesive made of acid-alkali resistant material has good chemical resistance and physical properties.
Application: Suitable for conveying corrosive materials containing acid in a chemical plant, chemical fertilizer plant, paper mill, etc.
Acid and alkali resistant conveyor belt (acid and alkali resistant conveyor belt) is suitable for a working environment in contact with acid and alkali, such as phosphate fertilizer manufacturing, seawater salt. An acid-alkali resistant conveyor belt (acid-alkali resistant conveyor belt) covering adhesive is made of rubber and plastic mixed and filled with material with excellent alkaline nature, which is better than neoprene in the acid-alkali resistant conveyor belt. The skeleton material adopts polyester canvas, which is more reliable than cotton canvas core belt in resisting acid and alkaline.
Baoxiang is a multifunctional conveyor belt manufacturers that integrates production line development, manufacturing, debugging and technical transformation. Its products include conveyor belting, nylon conveyor belt, etc.
Our website:
Contact Us
- HEBEI BAOXIANG CONVEYOR BELT MANUFACTURING CO.,LTD
- Contact nameWei Wang
- Phone86-0312-8718777
- AddressBoye County Baoding,Hebei
