Home > Products > Corrugated Sidewall Conveyor Belt > Corrugated Sidewall Conveyor Belt Large inclination Angle side guard conveyor belt construction conveyor belt
Corrugated Sidewall Conveyor Belt Large inclination Angle side guard conveyor belt construction conveyor belt
- 2000 Roll / Rolls per Month
- Tianjin
- T/T L/C
Product Details
Brand Name: | Baoxiang |
Product Description
Corrugated Sidewall Conveyor Belt Large inclination Angle side guard conveyor belt construction conveyor belt
Baoxiang corrugated conveyor belt DESCRIPTION
Base band: the skeleton material adopts polyester-cotton impregnated canvas (EP canvas, steel rope core) and transverse rigid reinforcing layer; adding lateral rigid reinforcement layer into the belt body solves the problem of belt collapse of large size blocking conveyor belt.
Side guard: according to the function of the side guard and the operation characteristic of the whole belt, measures such as increasing the glue content of the side guard and adding nylon cloth as the skeleton layer are adopted.Enhanced the bending resistance and tear resistance of the retaining edge, and increased the service life of the side guard.
Clapboard: adopt the mixing process of rubber material and fiber composite material to make the clapboard has great rigidity, high hardness, enhanced impact resistance, and avoid deformation due to the large force.
Adhesion of base band, side guard and baffle: adopt the advanced technology of secondary synchronous low-temperature continuous vulcanization, improve the bonding strength, and avoid aging base band due to multiple high temperature vulcanization.
Large inclination Angle side guard conveyor belt
Features: Suitable for conveying bulk materials with an inclination of 0° ~ 90°; With a wide range of use, small floor space, no transfer point, reduce civil investment, low maintenance costs, large throughput, etc. Solved the common belt and the pattern belt can not reach the transmission Angle; Also according to the use of the environment, the design of a complete, independent transport system, to avoid intermittent transport and complex transport lifting system.
The specifications and dimensions of the standard models of the side guard belt and side guard diaphragm are shown in the chart below
WK60 | WK80 | WK120 | WK160 | S160 | S200 | S240 | S300 | |
Sidewall highly | 60 | 80 | 120 | 160 | 160 | 200 | 240 | 300 |
Sidewall bottom width | 50 | 65 | 82 | 85 | 75 | 75 | 90 | 90 |
Sidewall amplitude | 36 | 46 | 52 | 62 | 65 | 65 | 84 | 84 |
Sidewall pitch of waves | 50 | 60 | 70 | 70 | 65 | 65 | 70 | 70 |
Sidewall weight | 1 | 1.38 | 3.04 | 4.4 | 4.65 | 6.20 | 8.30 | 10.85 |
Fold flat in meters | 0.67 | 0.92 | 2.03 | 3.2 | 2.7 | 3.6 | 4.8 | 6.3 |
Roller diameter | 400 | 500 | 600 | 800 | 800 | 900 | 1000 | 1200 |
Sidewall pressing wheel diameter | 280 | 340 | 360 | 480 | 480 | 600 | 420 | 600 |
Partition Height | 55 | 75 | 110 | 145 | 145 | 180 | 220 | 280 |
Partition bottom width | 6580 | 7570 | 120 | TC145 | TC145 | TC200 | TC200 | TC200 |
Partition fold flat in meters | 0.60.67 | 1.021.0 | 1.7131.83 | 2.37 | 2.30 | 3.39 | 5.0 | 6.6 |
Partition form applies to angles | T-45 TC-60 CTC-90 TC TCS-90 TCS | |||||||
Empty edge size | 60-300 |
Baoxiang is a multifunctional conveyor belt manufacturers that integrates production line development, manufacturing, debugging and technical transformation. Its products include conveyor belting, nylon conveyor belt, etc.
Our website:
Contact Us
- HEBEI BAOXIANG CONVEYOR BELT MANUFACTURING CO.,LTD
- Contact nameWei Wang
- Phone86-0312-8718777
- AddressBoye County Baoding,Hebei
