Home > Auto, Motorcycle Parts & Accessories > Vehicle Repair Equipment & Tools > Diagnostic Tool > 220V/380V Power Supply CR300 Common Rail Injector Test Bench
220V/380V Power Supply CR300 Common Rail Injector Test Bench
US$ 3,200 - 3,600
MOQ: 3 Units
Key Specifications
Get Latest Price
Brand Name:
haoshiyuan
Place of Origin:
Shandong, China
Model Number:
CR300
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CR825 Test Bench to Test Most of the Common Rail Injectors and PumpsUS$ 10,000 - 12,000MOQ: 1 Set -
CR 815 Full Function Common Rail Injector Test BenchUS$ 6,200 - 8,000MOQ: 1 Piece
-
China Factory Made Common Rail Test Stand Injector Tester Diesel Common RailUS$ 5,000 - 6,900MOQ: 1 Set
-
COMMON RAIL PUMP INJECTOR TEST BENCH CR815 WITH EUI EUP HEUIUS$ 5,000 - 7,000MOQ: 1 Set
-
CR825 Diesel Test Bench Common Rail Diesel Injector Pump CR825US$ 11,000 - 15,000MOQ: 1 Set
Brand Name
haoshiyuan
Place of Origin
Shandong, China
Model Number
CR300
Type
Engine Analyzer
Certification
iso
Voltage
380v or 220v
Power
5.5kw
Warranty
12 Months
Applicable Models
all trucks
Product Description
CR300 Common rail injector test bench
Bosch 10A code generation
IQA code can customize each condition
Fuel injection without the need to repair the injector
Injector armature stroke lift test
Rail pressure up to 2600 bar
The working oil temperature is not higher than 42 degrees for 24 hours.
High reliability of equipment, no failure throughout the year
Response time test
Solenoid valve resistance test
Solenoid valve inductance test
Turn on the pulse width test
Open stress test
Common rail injector test bench
Test Range
Can test below control system:
Bosch, Denso, Delphi, Siemens
Caterpillar
Power supply | 220VAC/380VAC |
Phase Single | phase/ Three phase |
Frequency | 50Hz/60Hz |
Current | 30A(Max) |
Motor Power | 5.5Kw |
Oil temperature control | Heating /strong cooling wind |
Oil temperature setting | 40 degrees Celsius |
Use ambient temperature | less than 35 degrees Celsius |
Maximum common rail pressure | 180-240Mpa |
Common rail pump Bosch | CP3.3 |
Control loop voltage | DC24V/DC12V |
ECU internal boost | 0-200VDC(Max) |
Test tank volume | 19L |
Noise level | <85dB |
Weight | 350kg |
Net size (L*W*H) | 120*85*141cm |
Wooden package size (L*W*H) | 130*95*150cm |
Packing & Delivery
Packaging | ||
Size | 160 (L) * 980 (W) * 1200 (D) | |
Weight | 350kg | |
Packaging Details | The normal package is polywooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. | |
Company Profile
Tai'an haoshiyuan automobile testing equipment company has its own factory, and Italy is a joint venture founded in 1995, the company is located in the beautiful at the foot of Taishan, the existing 5 million yuan in fixed assets, more than 80 employees. Several of the earliest engaged in the frequency conversion speed injection pump test bench of senior engineers, engineers, technicians and computer software and hardware development experts. The introduction of advanced production and processing equipment and a full set of production technology and product design software, Italy has the world's advanced level of a variety of automotive testing and testing equipment.
Why Choose Us
Product production process using microcomputer control and digital display system, advanced production technology, strong technical force, can produce a variety of equipment 2330. Product quality, high technical performance, with micro control and digital display function. Products are sold all over the country, exported to more than and 20 countries and regions in the world.
Our business purpose is: by virtue of strong technical force, advanced equipment and scientific management to produce high quality products.
The company products Three Guarantees, transport agent, life-long service, training and technical personnel, to provide long-term technical advice
Our business purpose is: by virtue of strong technical force, advanced equipment and scientific management to produce high quality products.
The company products Three Guarantees, transport agent, life-long service, training and technical personnel, to provide long-term technical advice
