Lower price BD850-CMC diesel fuel injection pump test bench
BD850-CMC series diesel fuel injection test bench is design for customer's requirement.
This series test bench adopt high quality frequency converter, and it has characteristic with hi-reliability, ultra-low-noise, energy save, high output torque, perfect auto-protecting function and operate easy.
It is the kind of product with high quality and good price in our business.
Test Cylinders | 12 |
Rotation Speed | 0~4000 rpm |
Double Series of graduates | 45cc, 150cc |
Volume of Diesel fuel tank | 60L |
Temperature automatic control | 40±2℃ |
Test Oil Filtering Unit | <5u |
DC Supply | 12V / 24V |
Feed Pressure | low: 0~0.4Mpa , high:0~4Mpa |
Air Pressure | positave: 0~0.3Mpa, negative: -0.03~0Mpa |
Flywheel Inertia | 0.8kg.m2 |
Center Hight | 125mm |
3 phase power resource | 380V/50HZ or 220V/60HZ, optional |
Output Power | 5.5KW, 7.5KW,11KW,15KW,18.5KW optional |
CHARACTERISTICS
1. Changing frequency changing rotation speed;
2. Low fall of rotation speed and high output torque;
3. High measurement precision;
4. The functions of over voltage, overload and short circuit protection;
5. Ten kinds of rotation speeds presetting;
6. Constant temperature controlled;
7. Ultra low noise;
8. Operating position: arbitrary side of the two work sides of the test stand;
9. Rotation speed, count, temperature, air pressure and advance angle are displayed on LCD;
10. Built-in air resource;
11. Data can be searched, printed(options).
BD850-CMC Diesel Fuel Injection Pump Test Bench
1.Measurement of each cylinder delivery at any speed.
2.Test point and interval angle of oil supply of injection pump.
3.Checking and adjust the mechanical governor.
4.Checking and adjusting the distributor pump.
5. Experiment and adjusting of behavior of supercharging and compensatory device.
6.Measurement of oil return of distributing pump
7.Testing of the electromagnetic valve of distributor pump.(12V/24V)
8.Measurement of the internal pressure of distributor pump.
9.Checking of the advance angle of advance device.(on request)
10.Checking the sealing of injection pump body
11.Install tube of auto-sucking oil supply can check on oil supply pump(including VE pump.)
BD850-CMC Diesel Fuel Injection Pump Test Bench
Packing : Export Wooden Case
Size: 1.9*0.85*1.7m
N/W: 800kg
Delivery: 20 days after receive downpayment.
