Diesel Fuel Tank Cleaning Machine-Newest Type
- 1000 Set / Sets per Month
- Qingdao
- T/T Credit Card
- The Most Professional Diesel Tank Cleaning Machine
- The Biggest Manufacturer of Diesel Tank Cleaning Machines
- Diesel Fuel Tank Cleaning Machine
- motor diesel tank ultrasonic cleaning machine
- diesel fuel tank cleaning machine
- High Quality Diesel fuel oil tank car cleaning machine/2020 Manufacturers selling diesel tank cleaning equipment using easily
Product Details
Brand Name: | Xinbaodi | Place of Origin: | Shandong, China | Model Number: | XBD-T |
Product Description
2013 diesel tank cleaning machines
Diesel tank cleaning machine is designed for automotive diesel fuel tank cleaning dirt. Can be tanks in the same time, filter out impurities and water quality, filtration efficiency reached 90%. Cleaning, using circular filtering method, you can no longer crack unloading tank, do not add any chemical reagents, than the loss of diesel fuel tank in the case of a diesel tank will be cleaned.
Works
Diesel washing machine for cleaning of various models of diesel carriages, cleaning the fuel tank when the fuel tanks and pipelines do not need to be demolished, its working principle is to control by the oil control in the diesel fuel out of the tank into the rough filtration tank to the primary filter, large particles will be to filter out the impurities and water, and then, after pressure from the gear pump into the tank will be fine-fine particle filter through the deep filter to filter out impurities. After two clean diesel filtration pressure of 1.5 kg of high-pressure nozzle from the fuel tank, wherein the side chamber and the corners will be inside the fuel tank along with magazines and muddy to 30 liters per minute of traffic circulation and filtering. Ultimately within the diesel fuel tanks and fuel tanks to clean.
How
Method 1; direct cyclic cleaning method
1. Would be an appropriate point of bent heads, through the partition hole on the side of cavity inserts
2. The pump tubing inserted in the tank and cleaning the lowest point or side-angle hole cavity
3. Connected to the power will be transferred to shun switch to switch, that is, washing machine direction of the normal cleaning 4. Hand-held boom with a nozzle spray tank walls and corners key
Method 2: emptying Circulation cleaning
1. Will be a clean vessel into the fuel tank below to open the mailbox at the bottom of oil discharge screw, diesel full release
2. Will take the oil pipeline into the container, the injection tube into your mailbox
3. Connected to the power will be transferred to shun transfer switch
4. Back and forth moving fuel injection dry, dry the bottom of the fuel injection nozzle is fully clean every corner of the fuel tank, focusing on cleaning the inside of the fuel tank and the dead
Warm Tips
Method 1, the proposed tire paving the first side of the 5-10 cm, the fuel tank may have a certain tilt of
Inside the fuel tank less than 1 / 2 or an empty tank, suggested that with a rotating nozzle cleaning
Redundant within the fuel tank 1 / 2, suggested that washing things by direct spray
Notes
1. To replace sprinklers should be tightened to prevent falling in the mailbox
2. Veering when the pump if the pressure of more than 2.5 kilograms, said the details filter blocked, it is timely shutdown, cleaning or replacing filters to prevent motor burnout
3. Pump in the downturn, wary of pumping oil pipeline blockage. Coarse filter cylinder pressure will lead to more than 1.5 kilograms of glass broken window
Maintenance and repair
4. One-way motor using three core plugs, maintenance need to unplug the power plug and pay attention to capacitor discharge
5. If the motor starts running weak or difficult to stop, and so on, due to power supply to the washing machine outlet diameter thin line between the lead voltage is too low too long. So, please timely replacement of large diameter wire.
Filter Replacement
1. Will be pumping all the oil pipeline at the nozzle pulled out of oil, non-contact oil
2. Kai-shun turn, to the injector nozzle is not
3. Open to change, to smoke is no longer tubing injector
4. Open the rough filtration of sewage valve
5. Open the fine filter sewage valve, will come with all the impurities in diesel exhaust
6. Open the fine filter replacement filter tank.
