Advantages:
1. Cutting edge straight
2. The machine is not easy to deform
3. Quality assurance:
Standard parts, high precision, quality inspection
4. Good quality belt and pulley
5. Button:More than 10000 times
6. Overload protection
7.The operation is simple and the work efficiency is extremely high.
Product Description
1.Applicable Products: MDF, particleboard, wood-based panels, ABS panels,PVC panels, plexiglass, solid wood and other wood structure and hardness similar to the plate.
2.How it works: Hand move the mobile workbench before and after the move to achieve the sawing process, scribe saw sawing in advance, the main saw blade can be used to carry out variable speed sawing.
3.To achieve the effect: Manual and easy to feed when the labor-saving, high precision, access to good quality sawing.
4.Structural advantages: Mobile workbench guide rail with high strength extruded aluminum alloy, high strength, non-deformation, chrome rod structure, high positioning accuracy, table surface oxidation treatment, beautiful wear-resistant.
Product parameters
Model | J-30E | Small motor power | 1.1 KW |
Sliding table size | 3200 x 410 mm | Diameter of Auxiliary Shaft | 20 mm |
Maximum cutting length | 3100 mm | Voltage | AC380V/50Hz, 3-phase |
Maximum cutting width | 1270 mm | Operational mode | Computer Digital Control |
Angle | 0-45° | Angle adjustment | Automatic tilt |
Diameter of large saw blade |
300 mm | Lift adjustment of large saw blade |
Automatic lifting |
Maximum Cutting Height at 90 |
80 mm | Right Side Length Moving Mode |
Computer Digital Mobile |
Speed of large saw blade | 3000/4000/5000 r.p.m | Left Size Reading Mode | Grating ruler reading |
Main motor power | 5.5 KW | Lubrication mode | Oil Cup Injection |
Spindle diameter | 30 mm | Dust Collection Method | Bottom dust collection plus top dust collection |
Diameter of small saw blade | 120 mm | Weight | 1000KG |
Speed of small saw blade | 8000 r.p.m | Packing dimensions | 3000 x1100 x 1000 mm |
Contact
TAIAN XINBAODI EXPERIMENTAL EQUIPMENT CO., LTD
Add : NO. 1#-2-402,WEST OF DONGYUE STREET, TAIAN CITY, SHANDONG, CHINA
Mob:0086-15269868592
WeChat: 0086-15269868592
WhatsApp: 0086-15269868592
Skype: testbench201010
E-mail: testbench2017@outlook..com
Website: https://xinbaodi.en.china.cn
FAQ
1. Q: Are you trading company or manufacturer?
A:we are manufacturer. We have had test bench for 20 years.
2. Q:How long of warranty?
A:14 months warranty for our product, whole life technical support. we have 10 professional business managers who can serve clients in 24 hours.“we have professional training activities.” every month our company organize training to improve the service level.
3Q: What is your terms of payment?
A: T/T, Western Union, etc.
4Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, The specific delivery time depends on the items and the quantity of your order..
5Q: Why should I choose your product?
A: We can provide you the best quality and the most competitive price ,and we have our own engineer, if you have any requirements you can contact us directly.
6Q. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
7Q. What is your terms of delivery?
A: EXW, FOB, CFR, CIF.
8Q. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
9Q: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
