Cr3000a-708 Common Rail Test Bench/piezoelectric High Pressure Diesel Fuel Common Rail Injector Pump Test Bench
- Qingdao or as your requirements
- T/T Credit Card
You May Like
-
CRS 706 High Pressure Common Rail Injector Test Bench
-
Factory Sales Heavy-duty Automatic Touch Screen Shaped Sander-9Z Sanding Woodworking Machine/brush Polishing Sanding Machine
-
Diesel Tank Cleaning Machine Vessel Cleaning Machine Diesel Calibrating Machine for Diesel Vehicles Car Heavy Truck
-
BD850 Rabotti Diesel Injection Pump Test Bench/fuel Injection Test Bench
-
The Factory Original Tool Trimming Knife for Vacuum Membrane Press Machine,door and Cabinet Door PVC Film Cutting Edge
-
Vacuum Membrane Press Machine Auxiliary Tools Heat Resistance Tear Silicone Rubber Sheet for Hot Transfer
Product Details
| Brand Name | XBD | Place of Origin | Shandong, China | |
| Model Number | CRS-708 | Power | Electronic |
Product Description
manufacturer pricexinbaodi CRS EPS 708 piezoelectric high pressure diesel fuel common rail injector pump test bench
CRS-708D Common Rail High-Pressure Test Bench
CRS-708D test bench is special device to test the performance of high-pressure common rail pump and injector, it can test common rail pump, injector and piezo injector. It tests the common rail injector and pump by flow meter sensor with more precise and stable measurement.Advanced technology, steady performance, precise measurement and convenient operation.
CRS-708D can fulfill the remote assistance by internet and make the maintenance easy to operate.
CHARACTERISTIC
1. Main drive adopts the speed change by frequency change.
2. Controlled by industrial computer in real time, Windows operating system. Fulfill the remote assistance by internet and make the maintenance easy to operate.
3. Flow is measured by flow sensor and displayed on 19 inch LCD .
4. Control the rail pressure by DRV, rail pressure can be tested in real time and controlled automatically, it contains the high-pressure protection function.
5. Oil temperature is controlled by forced-cooling system.
6. Pulse width of the injector drive signal can be adjusted.
7. Protection function of short-circuit.
8. Plexiglass protective door, easy operation, safe protection.
Injection testing frequency | 50~3000 rpm |
Fuel temperature | 40±2°C |
Rail high pressure | 0~1800 bar |
Test oil filtered precision | 5μ |
Input power | 380V/50hz/3phase or 220V/60hz/3phase |
Rotation speed | 0~4000RPM |
Oil tank capacity | 60L |
Flywheel inertia’s moment | 0.8KG.M2 |
Center height | 125MM |
Output power | 11KW |
Overall dimension(MM) | 1900×800×1550 |
Weight | 800 kg |
Package
The package is wooden case or plywood case, if you need, we can also pack the products according to your demands.
Other products
We have more model products for testing traditional mechanical pump.
Such as XBD-619S screen display test bench by
FAQ
Q: How many days to produce this test bench?
A: It need 5-20 days to produce the test bench.
Q:How can I pay for it?
A:We support TT payment, West Union, and L/C etc.
Q:How to sign an order?
A:We can sign an order offline or online on Ali.
Q:How long of warranty?
A:12 months
