Clutch Test Equipment
- Qingdao China
- T/T Credit Card
You May Like
Product Details
| Brand Name | Haolida | Place of Origin | Shandong, China | |
| Model Number | HLD-QCJ-3 | Power | Electronic |
Product Description
HLD-QCJ-3 model Clutch Test Equipment
General introduction
QCJ-3 ModelAutomobile Clutch Disassembly&Test Bench is applicable for disassembling and testing the clutch of all trucks and buses. This equipment has reusable structure, convenient operation and accurate test data.
Test items:
l Spring pressure of clutch
l Friction torque of friction disk
l Clutch gap of friction plate
Technical parameter:
Model no | QCJ-3 |
Language | English, etc |
Material | Metal plate |
Painting | Powder painting, durable and beautiful |
Color | Blue |
Voltage | 380V 50Hz |
External air source | 1.0Mpa |
Air cylinder stroke | 260mm |
Max tested pressure value | 2000kg |
Max tested torque value | 1500N.m |
Maximum stroke of indenter sliding column | 250mm |
Transmission ratio of worm gear case | 1:50 |
Accessories: | |
Accessory wires, etc. | |
Others you may want to know: | |
MOQ | 1set |
Warranty period | 12 months |
Payment term | T/T 50% in advance, the balance should be paid before delivery (negotiable) |
Delivery time | 30 days after receiving downpayment |
HS code | 90312000.90 |
Packing sizes | 1870*1020*1660mm=3.17CBM |
Why Choose us:
1. 32 years’ design,development and produce experience
2. Professional R&D team
3. Strict QC
4. A good pre-sale and after-sale service
5. Can design and make according to customer’s requests
