HLD-QDS-3 model Computer Control Starter Motor Test Bench
General introduction
1. It can be used to test Starters of various vehicles (Car, Truck, Bus, Tractor, Excavator, etc);
2. Test Starter: 15KW, 0-2000A, 0-200N.M, 12V or 24V or 48V
3. It is matched with PLC computer to operate, too see and test process and results directly, it can save & print test results and curves.
Test items:
1. Test no load performance of starter: no load current, no load voltage, no load speed
2. Test load performance of starter: load current, load voltage, load torque, load speed
3. Test braking performance of starter: braking voltage, braking current, braking torque
4. Test electromagnetic coil of starter: pull and suck voltage ,current
Technical parameter:
Model no |
HLD-QDS-3 |
Language |
English/Spanish, etc |
Material |
Metal plate |
Painting |
Powder painting, durable and beautiful |
Color |
Blue |
Voltage |
220V 50Hz |
Motor power |
7.5KW |
Starter testing: | |
Maximum Power |
15KW |
Maximum current |
2000A |
Maximum torque |
200N.m |
Test solenoid excitation voltage |
12V/24V |
Need external battery |
12V/24V/48V, choose according to starter type |
Pressure set |
0-1.0Mpa (adjust randomly) |
Starting time |
0-9.9s (set randomly) |
Starter braking |
Hand wheel control, pneumatic hydraulic |
Accessories: | |
Accessory wires, blank plates for starters, etc. | |
Others you may want to know: | |
MOQ |
1set |
Warranty period |
12 months |
Payment term |
T/T 50% in advance, the balance should be paid before delivery (negotiable) |
Delivery time |
35 days after receiving downpayment |
HS code |
90312000.90 |
Packing sizes |
1870*1020*1660mm=3.17CBM |
Why Choose us:
32 years’ design,development and produce experience
Professional R&D team
Strict QC
A good pre-sale and after-sale service
Can design and make according to customer’s requests
