| Project | Specification | ||
| Product number | 4LZ-5(PRO1108) | ||
| Classification | Air-condition cabin | ||
| Dimensions | Length (mm) (transport status / working status) | 5900/5971 | |
| Width (mm) (transport status / working status) | 2900/2900 | ||
| Height (mm) (transport status / working status) | 3350/3350 | ||
| Structure quality (kg) / quality of use (kg) | 4785/5210 | ||
| Matching engine | Model (China third stage) | V3800-DI-TI-ET08 | |
| Structure type | Vertical water cooled 4 - cylinder turbocharged diesel engine | ||
| Total Displacement (L) | 3.769 | ||
| Calibration power (kW) | 80.1 | ||
| Calibration speed (r / min) | 2600 | ||
| Fuel | High quality diesel (0 #) | ||
| Fuel tank capacity (L) | 250 | ||
| Walking part | Tire | Drive wheel (front wheel) track | 1880mm |
| Guide wheel (rear wheel) track | 1890mm | ||
| Wheelbase | 2855mm | ||
| Gearbox type | Mechanical shifting + hydraulic stepless shifting (HMT) | ||
| Variable speed series | Stepless forward stepless stepless (second gear speed 2 gears) | ||
| Minimum ground clearance (mm) | 290 | ||
| Cutting table | Cutting table width (mm) | 2300 | |
| Adapt to crops | Rice, wheat | ||
| Grain processing department | Way of food | Single-direction automatic unloading of grain (hydraulic tipping bucket + unloading grain cylinder) | |
| Granary capacity (L) | 2400 | ||
| Unloading grain | Unloading grain unloading height range (mm) (working state) | 2400 | |
| Unloading mouth out of the distance range (mm) (working state) | 2150 | ||
| Alarm system | Water temperature, charge, oil, gluten full, 2 snuff plug, reverse fan | ||
| Operating hours productivity (hm² / h) | wheat: 0.5 ~ 0.8 rice: 0.3 ~ 0.5 | ||
Q1. What is your terms of packing?
A: Generally, we pack our goods in our W brand box ..
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF.
Q4. How about your delivery time?
A: Generally, most of items we keep stock for all season . it will take 7to 10 days after receiving your advance payment. .if we didn’t have stock ,The delivery time depends on the items and the quantity of your order. Normaly 30 to 60days .
Q5. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q7. Do you inspect all your goods before delivery?
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
1.Meet small quantity orders and seasonal orders by our sufficient safety stock;
2.Assure best quality with our complete inspection system before shipment
3.Ensure timely delivery to customer’s designated site by our professional management of warehouse and van fleet;
4.Provide in time Feedback tracking and after-sales services to maximize the customer’s satisfactory.
