1500KG Mini Cheap Excavator for Sale

1500KG Mini Cheap Excavator for Sale photo-1
1500KG Mini Cheap Excavator for Sale photo-2
1500KG Mini Cheap Excavator for Sale photo-3
1500KG Mini Cheap Excavator for Sale photo-4
1500KG Mini Cheap Excavator for Sale photo-5
1500KG Mini Cheap Excavator for Sale photo-6
1500KG Mini Cheap Excavator for Sale photo-7
US$ 13,790 - 13,967 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
nuoman
Place of Origin:
Shandong, China
Certification:
CE ISO
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Brand Name nuoman
Place of Origin Shandong, China
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas
Condition New
Machine Weight 1500kg
Moving Type Crawler Excavator
Rated Speed 1.5km/h
Max Digging Radius 3470mm
Maximum Digging Depth 3470mm
Maximum Digging Height 2150mm
Bucket capacity 0.035m3
Operating Weight 1500kg
Product Description

Product Application

Low fuel consumption, wide scope of operation, suitable for loose land in vegetable shed, landscaping in municipal departments, planting of trees and pits in orchard nurseries, broken concrete pavement, agitation of sand and stone, construction of narrow space, etc., Can equipped with rotary drilling, broken hammer, loading bucket, grab, etc., reduce maintenance and operation costs, liberate labor force, improve mechanization, low investment, high return.

SPECIFICATIONS FOR MINI EXCAVATOR
NM-16
Engine
YANMAR370
Max. Digging depth
2150mm
Hydrulic pump
KADEKOR
Max. Vertical digging depth
1750mm
Walking motor
eaton
Min. turning radius
1440mm
Rotary motor
eaton
Platform back turning radius
740mm
Multiple unit valve
imported
Max. dozer blade rising height
285mm
Track
rubber230
Max. dozer blade digging depth
195mm
Track tighten model
Tighten oil cylinder
Max. walking speed
1.5km/min
Digging bucket capacity
0.035m3
Turning speed
11rpm
Size
3290*1050*2400mm
Max. grade ability
30°
Total height
2400mm
Digging bucket ability
10.5kn
Seat height
1660mm
Max. movable arm ability
6.5kn
Machine weight
1500kg
Max. Tractive effort
13.5kn
Wheele-base
1290mm
Ground pressure
35kgf/cm2
Track length
1670mm
Hydrulic pump
gear pump
Table to ground height
460mm
Working pressure
16MPA
Max. Digging height
3275mm
Hydrulic oil tank
15.3L
Max. Dumping height
2310mm
Engine oil tank
2.8L
Max. Digging radius
3470mm
Diesel oil tank
16.4L

Main Features

1. Engine: YANMAR370
2. Hydraulic pump (gear pump) is easy to maintain, long life
3. System pressure: 16Mpa
4. Multiple valves under the operating handle
5. Rubber track no damage to cement, tile floor
6. Diesel level gauge: Check engine oil when it is not easy to start

Detailed Images
Our Service

We have an independent factory, with 12 years of independent r & d production experience。
Strict quality control system, each product will exceed 12 hours of quality inspection, to ensure product quality。
We have a professional after sales team, 24 hours online for you to solve any product question
Support products to customize, can be tailored according to your requirements
Fast shipment, safe packing, ensure the goods are in good condition and timely delivery to you

Packing & Delivery
FAQ

1.Q: How can I make the payment?
A:Sample orders 100% T/T in advance. If mass order, T/T L/C are acceptable.
2. Q: Can i have any free sample of the machine if my order is big enough?
A: Yes, of course !
3. Q: Can I order mix order?
A:Yes.
4. Q: How long of the warranty period?
A: 1year
5. Q: How about delivery?
A:delivery:7-10 working days after payment
packing: A:container or Standard wooden case package
B:Nude package or according customers requirements
6. Q: How can i believe you and your factory?
A:Since it is not the little thing to purchase machine, you can come to China to visit us for an inspect, and we will welcome you enthusiasm. so we can establish good cooperation with each other.
Reply you in 24 hours, if you are urgent, we can reply you soonest.
