Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Excavator > 1.6 Ton Mini Excavator for Sale
1.6 Ton Mini Excavator for Sale
US$ 13,600 - 13,990
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Nuoman
Place of Origin:
Shandong, China
Model Number:
NM-E16
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
FREE SHIPPING for Small Chinese Mini Excavator for Sale Prices Towable Mini Excavator 800kg With CE/ISOUS$ 2,750 - 3,300MOQ: 1 Set -
Supply New Excavator Price Factory DirectUS$ 5,978 - 14,798MOQ: 1 Set
-
China Mini 620kg Digger MachineUS$ 3,794 - 3,851MOQ: 1 Set
-
New Price of 1780 kg Mini Excavator for SaleUS$ 9,500 - 12,000MOQ: 1 Set
-
Cheap 1880kg Mini Excavator Spare Parts for SaleUS$ 6,199 - 12,352MOQ: 1 Set
Brand Name
Nuoman
Place of Origin
Shandong, China
Model Number
NM-E16
Certification
CE ISO
After-sales Service Provided
Engineers available to service machinery overseas
Condition
New
Machine Weight
1550kg
Moving Type
Crawler Excavator
Rated Speed
1.5km/h
Max Digging Radius
3470mm
Maximum Digging Depth
2150mm
Maximum Digging Height
3275mm
Bucket capacity
0.045m³
Operating Weight
2200kg
1.6 ton mini excavator for sale
Product Description
This excavator is designed for small works, small projects, in garden, farmland, municipal works,vegetable greenhouse, digging trench It is with small engine, simple design, easy to maintain.
specifictions
| Engine | Unit | Specificatin | |
| Vehicle weight | kg | 1550 | |
| Standard shovel capacity | m³ | 0.045 | |
| Working device form | backhoe | ||
| Model | Yanmar 3TNV70 | ||
| displacement | L | 0.854 | |
| Rated output power / speed | kw/r/min | 10/2200 | |
| Maximum torque | N.M/r/min | 51.9/1600 | |
| Maximum walking speed | km/h | 1.5 | |
| Gyration speed | rpm | 11 | |
| Max Climb Capability | 30° | ||
| Excavating power of dug | KN | 10.5 | |
| Bucket excavating force | KN | 6.5 | |
| Maximum traction | KN | 13.5 | |
| Ground specific pressure | kgf/cm² | 35 | |
| Caterpillar material | rubber | ||
| type of rising device | Butter cylinder | ||
| pump form | gear pump | ||
| Working pressure | MPA | 16 | |
| flow | L/min | 23.3 | |
| Hydraulic tank capacity | L | 15.3 | |
| Maximum engine oil capacity | L | 2.8 | |
| Fuel tank capacity | L | 16.4 | |
| Dimendions | Unit | Specificatin | |
| Wheelbase | mm | 1130 | |
| Caterpillar chief | mm | 1450 | |
| Platform clearance | mm | 437 | |
| Platform end radius of gyration | mm | 740 | |
| Chassis width | mm | 1130 | |
| track width | mm | 230 | |
| Track Height | mm | 320 | |
| Transport length | mm | 3160 | |
| Full vehicle height | mm | 2377 | |
| Operating range | Unit | Specificatin | |
| Maximum ground mining radius | mm | 3470 | |
| Maximum mining depth | mm | 2150 | |
| Maximum mining height | mm | 3275 | |
| Maximum unload height | mm | 2310 | |
| Maximum vertical excavator depth | mm | 1740 | |
| Minimum radius of revolution | mm | 1440 | |
| Maximum lift height of earth shovel | mm | 262 | |
| Maximum digging depth of earth shovel | mm | 192 | |
