60kn Soil Triaxial Shear Test Machine

60kN Triaxial Infinitively Variable Speeds Shear Test Machine

Application:

The Apparatus is used to determine the resisting shear strength of the soil specimen with maximum confining pressure of 2.0MPa and specimen dimension is of Φ61.8x125mm,Φ101x200mm. The apparatus can perform unconsolidated-undrained shear test (UU),consolidated-undrained shear test (CU), and consolidated-drained (CD) shear test. It consists of frame, test control device,pressure chamber and specimen tools etc.

Specimen:

Φ39.1mm x 80mm, Φ61.8mm x 125mm, Φ101mm x 200mm

Capacity:

60KN

Strain rate:

0.0001-4.8mm/min.

Platen travel:

0-100mm

Confining pressure:

0-2MPa Digital control and display

Back pressure:

0-1MPa Digital control and display

Pore pressure:(u)

0-2MPa

Volume deformation:

0-100ml,minimum resolution:0.2ml

Power supply:

220V±10% 50Hz

Weight:

240Kg (including main unit,controller,measuring equipment etc.)
