WE-D ISO DIN ASTM Price Tensile Tester Hydraulic Universal Testing Machine Price
1. Application
Steel Rebar ISO DIN ASTM Universal Tensile Testing Machine Is suitable for doing
testing experiments such as the tensile, compression, bending and sheartesting for all kinds of metal materials and nonmetal materials such as plastic, concrete, cement and so on.
2. Standards
ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN standards
3. Main Specifications
|
Model |
WE-100D |
WE-300D |
WE-600D |
WE-1000D |
|
|
Structure |
6 Column (Four Columns Two Ball Screws) |
||||
|
Control Way |
Loading Process Manual Control |
||||
|
Max. Load |
100 KN (10 TONS) |
300 KN (30 TONS) |
600 KN (60 TONS) |
1000 KN (100 TONS) |
|
|
Load Accuracy |
≤± 1% |
||||
|
Load Range |
2%~100%FS (2KN~100KN) |
2%~100%FS (6KN~300KN) |
2%~100%FS (12KN~600KN) |
2%~100%FS (20KN~1000KN) |
|
|
Load Resolution
|
0.01 KN |
||||
|
Piston Speed |
0-140mm/min
|
0-140mm/min
|
0-90mm/min
|
0-50mm/min
|
|
|
Crossbeam Lifting Speed |
190mm/min |
190mm/min |
190mm/min |
150mm/min |
|
|
750mm (Can Be Customized) |
650mm (Can Be Customized) |
||||
|
Max.Effective Compression Test Space |
600mm (Can Be Customized) |
500mm (Can Be Customized) |
|||
|
Center Spacing Between Columns |
490mm |
490mm |
540mm |
600mm |
|
|
Column Effective Spacing |
420mm |
420mm |
475mm |
525mm |
|
|
Max. Piston Stroke |
250mm |
||||
|
Clamping Method |
Manual Clamping / (Optional: Hydraulic Clamping) |
||||
|
Round Specimen Clamping Range |
Φ10-Φ20mm,Φ20-Φ32mm (Optional: Φ4-Φ10mm) |
Φ13-Φ26mm,Φ26-Φ40mm (Optional: Φ6-Φ13mm, Φ40-Φ50mm) |
|||
|
Flat Specimen Clamping Range |
0-15mm (Optional: 15-30mm) |
||||
|
Flat Specimen Clamping Width |
75mm |
75mm |
80mm |
80mm |
|
|
Compression Platen Size |
Φ 160mm |
||||
|
Span Of Bending Rollers |
450mm |
||||
|
Width Of Bending Rollers |
120mm |
||||
|
Power Supply |
3-Phase 4-Wires, AC 380V, 50Hz (Can Be Customized) |
||||
