WAW-L Computer Control /Digital Display Single Tensile Testing Machine
1. Application:
Computer Control /Digital Dispaly Single Tensile Testing Machine is applied in steel industry, the high fatigue metal rapid tensile testing.It adopt four-column single pull-type frame structures,realized the bi-directional oil cylinder rising and falling rapidly in a space,to adjust the testing space and tension-compression automatically.The whole test process with the same resolution.
2.Main Specifications:
Model |
WAW-300L |
WAW-600L |
WAW-1000L |
WAW-2000L |
|||
Control mode |
constant stress, deformation, displacement, three closed loop control |
||||||
Max. Load |
300kN |
600kN |
1000kN |
2000kN |
|||
Load range |
2%~100%FS |
||||||
Force resolution |
1/300000 |
||||||
Load accuracy |
≤±1% |
||||||
Deformation Measurement Range |
2% ~ 100% of extensometer measurement range |
||||||
Deformation indication error |
± 0.5%of indicating value |
||||||
Deformation resolution |
0.0001mm |
||||||
Displacement Indication Error |
1%of indicating value |
||||||
Displacement Resolution |
0.005mm |
||||||
Clamping Method |
Hydraulic clamping |
||||||
Control range of stress rate |
1MP/S-60MP/S
|
||||||
Adjust range of test strain rate |
0.00025/S-0.0025/S |
||||||
Max piston stoke |
600mm |
||||||
Max. Tensile Test Space |
500mm |
||||||
Round Sample Clamping Diameter: |
Φ13-Φ40mm |
Φ13-Φ40mm |
Φ20-Φ60mm |
Φ40-Φ80mm |
|||
Flat Sample Clamping Diameter |
0-30mm |
0-30mm |
0-40mm |
10-40mm |
|||
Voltage |
380V/50Hz/3Phase(can be customized) |
||||||
