The machine adopts hydraulic loading, Computer Display, easy and convenient to operate. It is mainly used to execute the tension, compression, bending, flexural etc. test for metal materials. Attached with simple accessories and devices, it can be used to test wood, concrete, cement, rubber, and so on.It is very suitable for making test to different metal or nonmetal materials under high toughness and hardness against extreme big loading force.
ISO6892, BS4449,ASTM C39,ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN standards.
Model |
WEW-1000D |
Structure |
4 columns and 2 screws |
Control way |
loading process manual control,computer automatic data dealing |
Max.load (kN) |
1000kN |
Load accuracy |
≤±1% |
Load range |
2%-100%FS |
Load resolution |
1/300000 |
Deformation Measurement Range |
2%~100%FS |
Deformation accuracy |
≤±1% |
Displacement resolution (mm) |
0.01 |
Displacement error |
≤±0.5% |
Max.piston stroke(mm) |
250 |
Max piston moving speed |
0-90mm/min Manual adjustment
|
Crosshead lifting speed |
200mm/min |
Max. tension test space |
980mm (can customize) |
Max.Compression Test Space |
700mm (can customize) |
