Single Space Tensile Strength Testing Machine for Reinforcement Steel Bars as per the British and American Quality Standards

Single Space Tensile Strength Testing Machine for Reinforcement Steel Bars as per the British and American Quality Standards thumbnail-1
Single Space Tensile Strength Testing Machine for Reinforcement Steel Bars as per the British and American Quality Standards thumbnail-2
Single Space Tensile Strength Testing Machine for Reinforcement Steel Bars as per the British and American Quality Standards thumbnail-3
Single Space Tensile Strength Testing Machine for Reinforcement Steel Bars as per the British and American Quality Standards thumbnail-4
Single Space Tensile Strength Testing Machine for Reinforcement Steel Bars as per the British and American Quality Standards thumbnail-5
Single Space Tensile Strength Testing Machine for Reinforcement Steel Bars as per the British and American Quality Standards thumbnail-6
Single Space Tensile Strength Testing Machine for Reinforcement Steel Bars as per the British and American Quality Standards photo-1
Single Space Tensile Strength Testing Machine for Reinforcement Steel Bars as per the British and American Quality Standards photo-2
Single Space Tensile Strength Testing Machine for Reinforcement Steel Bars as per the British and American Quality Standards photo-3
Single Space Tensile Strength Testing Machine for Reinforcement Steel Bars as per the British and American Quality Standards photo-4
Single Space Tensile Strength Testing Machine for Reinforcement Steel Bars as per the British and American Quality Standards photo-5
Single Space Tensile Strength Testing Machine for Reinforcement Steel Bars as per the British and American Quality Standards photo-6
US$ 19,600 - 40,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HST
Place of Origin:
Shandong, China
Model Number:
WAW-2000L
Contact Supplier Request Quote Chat Now
Jinan Hensgrand Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name HST
Place of Origin Shandong, China
Model Number WAW-2000L
Power Hydraulic

Single space tensile strength testing machine for reinforcement steel bars as per the British and American quality standards

Single space tensile strength testing machine for reinforcement steel bars as per the British and American quality standardsSingle space tensile strength testing machine for reinforcement steel bars as per the British and American quality standardsSingle space tensile strength testing machine for reinforcement steel bars as per the British and American quality standards

1. Application:

Computerized Single Pull Tensile Testing Machine/ High Quality Pull Fracture Testing Machine  is applied in steel industry, the high fatigue metal rapid tensile testing.It adopt four-column single pull-type frame structures,realized the bi-directional oil cylinder rising and falling rapidly in a space,to adjust the testing space and tension-compression automatically.The whole test process with the same resolution.

2.Standards:

ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN standards

3.Main Specifications:

Model

WAW-300L

WAW-600L

WAW-1000L

WAW-2000L

Control mode

constant stress, deformation, displacement, three closed loop control

Max. Load

300kN

600kN

1000kN

2000kN

Load range

                       2%~100%FS

Force resolution

1/300000

Load accuracy

           ≤±1%

Deformation Measurement Range

2% ~ 100% of extensometer

measurement range

Deformation indication error

± 0.5%of indicating value

Deformation resolution

0.0001mm

Displacement Indication Error

1%of indicating value

Displacement Resolution

0.005mm

Clamping Method

Hydraulic clamping

Control range of stress rate

1MP/S-60MP/S



Adjust range of test strain rate

0.00025/S-0.0025/S

Max piston stoke

600mm

Max. Tensile Test Space

                    500mm

Round Sample Clamping Diameter:

Φ13-Φ40mm

Φ13-Φ40mm

Φ20-Φ60mm

Φ40-Φ80mm

Flat Sample Clamping Diameter

0-30mm

0-30mm

0-40mm

10-40mm

Voltage

380V/50Hz/3Phase(can be customized)
