100ton 200ton 300ton Computer Control Hydraulic Chain Horizontal Tensile Testing Equipment

WAL-100ton 200ton 300ton Computer Control Hydraulic chain Horizontal Tensile Testing Equipment

Application:

The testing machine is mainly used to determine the tensile strength of electric cable, optic cable, steel wire rope, steel strand and other rope material. The testing machine adopts hydraulic cylinder to load, load cell to measure, computer to print and computer to display test data and other advanced technolog

Main technical parameter:

1. Max tensile force: 1000kn (or 600kN, 2000kN, 3000kN, 5000kN)

2. Test range: 2%~100%FS

3. Load accuracy:±1%

4. Display: Computer display, print,etc

5. WINDOWS interface operation, no language barrier, multilingual choose, report content modification function

6. Tensile distance: 1000mm (can customized)

7. Test speed: 0.1-300mm/min;

8. Max piston travel: 500mm (can customized)

9. Clamp: Bolt way/ hydraulic way

Configuration

1. Test machine host

Single out bar double action low friction piston cylinder------ 1 set

Oil cylinder block------ 1 set

Tensile test fixture----- 1 set

Host framework (using the steel plate welding structure)-------1 set

Safety protection device (including protective cover, etc).------ 1 set

2. Control cabinet

Bench hydraulic pump station--1 set

Italy MARZOCCHI import oil pump

3. Tester acquisition display system

AD800 universal test card---- 1 set

Maxtest tester special software under the WINDOWS98/2000 / XP operating environment------  1 set

High voltage control system---- 1 set

High precision load sensor----- 1 pc

4. Computer system:

LENOVO computer ----1set

HP printer---1set
